1775015 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
BOARD STACKING CONNECTOR, 12 CONTACT(S), 2 ROW(S), MALE, STRAIGHT, 0.031 INCH PITCH, SURFACE MOUNT TERMINAL, LOCKING, BLACK INSULATOR, PLUG
| Part | Number of Positions | Connector Type | Pitch [x] | Pitch [x] | Number of Rows | Height Above Board | Height Above Board | Mounting Type | Mated Stacking Heights | Contact Finish Thickness | Contact Finish Thickness | Features | Contact Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | 12 | Outer Shroud Contacts Plug | 0.8 mm | 0.031 in | 2 | 4.4 mm | 0.173 in | Surface Mount | 5 mm | 2.54 µm | 100 µin | Board Guide Solder Retention | Tin |
