002651 Series
Manufacturer: Molex
Beta
⌘K
CONN HEADER VERT 11POS 3.96MM
| Part | Applications | Style | Number of Positions | Mounting Type | Shrouding | Material Flammability Rating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Insulation Color | Contact Type | Contact Length - Post | Contact Length - Post | Contact Shape | Fastening Type | Connector Type | Overall Contact Length [x] | Overall Contact Length [x] | Contact Length - Mating | Contact Length - Mating | Insulation Material | Number of Rows | Number of Positions Loaded | Pitch - Mating | Pitch - Mating | Termination | Contact Material | Contact Finish - Post | Insulation Height | Insulation Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Automotive General Purpose Industrial Medical Telecommunications | Board to Board Cable | 11 | Through Hole | Shrouded - 1 Wall | UL94 V-0 | 5.08 µm | 200 µin | Black | Male Pin | 4.37 mm | 0.172 in | Square | Friction Lock | Header Breakaway | 19.05 mm | 0.75 in | 11.43 mm | 0.45 in | Polyester | 1 | All | 3.96 mm | 0.156 in | Solder | Brass | Tin | 0.5 " | 12.7 mm |
