800-10 Series
Manufacturer: Preci-Dip
Beta
⌘K
CONN HEADER SMD R/A 2POS 2.54MM
| Part | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Contact Material | Voltage Rating | Connector Type | Mounting Type | Insulation Material | Termination | Pitch - Mating | Pitch - Mating | Insulation Color | Material Flammability Rating | Insulation Height | Insulation Height | Contact Finish - Post | Fastening Type | Current Rating (Amps) | Contact Type | Shrouding | Contact Length - Mating | Contact Length - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish - Mating | Number of Positions | Contact Shape | Number of Positions Loaded | Number of Rows | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Length - Post | Contact Length - Post | Contact Length - Post [x] | Contact Length - Post [x] | Features | Overall Contact Length | Overall Contact Length | Number of Positions [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Preci-Dip | 10 Áin | 0.25 çm | Brass | 150 VDC | Header | Right Angle Surface Mount | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | 0.1 " | 2.54 mm | Black | UL94 V-0 | 0.1 in | 2.54 mm | Gold | Push-Pull | 3 A | Male Pin | Unshrouded | 4.85 mm | 0.191 in | -55 C | 125 °C | Gold | 2 | Circular | All | 1 | 0.25 µm | 10 µin | ||||||||
 Preci-Dip | 10 Áin | 0.25 çm | Brass | 150 VDC | Header | Through Hole | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | 0.1 " | 2.54 mm | Black | UL94 V-0 | 0.116 " | 2.95 mm | Gold | Push-Pull | 3 A | Male Pin | Unshrouded | 3.6 mm | 0.141 in | -55 C | 125 °C | Gold | 13 | Circular | All | 1 | 0.25 µm | 10 µin | 0.118 in | 3 mm | ||||||
 Preci-Dip | 10 Áin | 0.25 çm | Brass | 150 VDC | Header | Right Angle Through Hole | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | 0.1 " | 2.54 mm | Black | UL94 V-0 | 0.1 in | 2.54 mm | Gold | Push-Pull | 3 A | Male Pin | Unshrouded | 4.95 mm | 0.195 in | -55 C | 125 °C | Gold | 36 | Circular | All | 1 | 0.25 µm | 10 µin | 0.126 " | 3.2 mm | ||||||
 Preci-Dip | 10 Áin | 0.25 çm | Brass | 150 VDC | Header | Surface Mount | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | 0.1 " | 2.54 mm | Black | UL94 V-0 | Gold | Push-Pull | 3 A | Male Pin | Unshrouded | 3.6 mm | 0.141 in | -55 C | 125 °C | Gold | 4 | Circular | All | 1 | 0.25 µm | 10 µin | ||||||||||
 Preci-Dip | 10 Áin | 0.25 çm | Brass | 150 VDC | Header | Right Angle Through Hole | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | 0.1 " | 2.54 mm | Black | UL94 V-0 | 0.1 in | 2.54 mm | Gold | Push-Pull | 3 A | Male Pin | Unshrouded | 4.95 mm | 0.195 in | -55 C | 125 °C | Gold | 2 | Circular | All | 1 | 0.25 µm | 10 µin | 0.126 " | 3.2 mm | ||||||
 Preci-Dip | 10 Áin | 0.25 çm | Brass | 150 VDC | Header | Surface Mount | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | 0.1 " | 2.54 mm | Black | UL94 V-0 | 0.116 " | 2.95 mm | Gold | Push-Pull | 3 A | Male Pin | Unshrouded | 4.85 mm | 0.191 in | -55 C | 125 °C | Gold | 10 | Circular | All | 1 | 0.25 µm | 10 µin | Pick and Place | |||||||
 Preci-Dip | 10 Áin | 0.25 çm | Brass | 150 VDC | Header | Right Angle Surface Mount | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | 0.1 " | 2.54 mm | Black | UL94 V-0 | 0.1 in | 2.54 mm | Gold | Push-Pull | 3 A | Male Pin | Unshrouded | 4.85 mm | 0.191 in | -55 C | 125 °C | Gold | 44 | Circular | All | 1 | 0.25 µm | 10 µin | ||||||||
 Preci-Dip | 10 Áin | 0.25 çm | Brass | 150 VDC | Header | Surface Mount | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | 0.1 " | 2.54 mm | Black | UL94 V-0 | Gold | Push-Pull | 3 A | Male Pin | Unshrouded | 3.6 mm | 0.141 in | -55 C | 125 °C | Gold | 63 | Circular | All | 1 | 0.25 µm | 10 µin | ||||||||||
Preci-Dip | 10 Áin | 0.25 çm | Brass | 150 VDC | Header | Through Hole | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Solder | 0.1 " | 2.54 mm | Black | UL94 V-0 | 0.116 " | 2.95 mm | Gold | Push-Pull | 3 A | Male Pin | Unshrouded | 4.85 mm | 0.191 in | -55 C | 125 °C | Gold | Circular | All | 1 | 0.25 µm | 10 µin | 0.121 in | 3.08 mm | 0.438 in | 11.12 mm | 31 | ||||
 Preci-Dip | 10 Áin | 0.25 çm | Bronze | 150 VDC | Header | Through Hole | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Press-Fit Solder | 0.1 " | 2.54 mm | Black | UL94 V-0 | 0.116 " | 2.95 mm | Gold | Push-Pull | 3 A | Male Pin | Unshrouded | 4.85 mm | 0.191 in | -55 C | 125 °C | Gold | 2 | Circular | All | 1 | 0.25 µm | 10 µin | 0.15 in | 3.81 mm | 0.467 in | 11.85 mm |
