JF15AP1C Series
Manufacturer: NKK Switches
Beta
⌘K
TACTILE SWITCH, JF SERIES, TOP ACTUATED, THROUGH HOLE, SQUARE BUTTON, 300 GF, 50MA AT 24VDC
| Part | Switch Travel | Mechanical Life | Actuator Material | Operating Temperature [Min] | Operating Temperature [Max] | Outline [x] | Outline [y] | Termination Style | Illumination Voltage (Nominal) | Mounting Type | Actuator Type | Illumination Type, Color | Features | Operating Force | Illumination | Contact Rating @ Voltage | Circuit | Switch Function | Actuator Height off PCB, Vertical [z] | Actuator Orientation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NKK Switches | 0.4 mm | 500000 Cycles | Polyamide (PA) Nylon | -25 °C | 70 °C | 22.8 mm | 17.7 mm | PC Pin | 1.77 VDC | Through Hole | Square Button | LED Red | Process Sealed | 300 gf | Illuminated | 0.05 A 24 VDC | SPST-NO | Off-Mom | 6.7 mm | Top Actuated |
