LEA75F Series
Manufacturer: Cosel USA, Inc.
Beta
⌘K
AC/DC CONVERTER 15V 75W
| Part | Features | Applications | Current - Output 1 | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [x] | Efficiency | Type | Operating Temperature [Max] | Operating Temperature [Min] | Approval Agency | Voltage - Output 1 | Power (Watts) | Mounting Type | Voltage - Isolation | Number of Outputs |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cosel USA, Inc. | PFC Universal Input | ITE (Commercial) | 5 A | 55 mm | 8.74 in | 2.17 " | 29 mm | 1.14 in | 222 mm | 81 % | Enclosed | 70 °C | -20 °C | CE cURus TUV | 15 V | 75 W | Chassis Mount | 3000 V | 1 |
 Cosel USA, Inc. | PFC Universal Input | ITE (Commercial) | 2.5 A | 55 mm | 8.74 in | 2.17 " | 29 mm | 1.14 in | 222 mm | 84 % | Open Frame | 70 °C | -20 °C | CE cURus TUV | 30 V | 75 W | Chassis Mount | 3000 V | 1 |
Cosel USA, Inc. | Adjustable Output PFC Universal Input | ITE (Commercial) | 2.5 A | 55 mm | 8.74 in | 2.17 " | 29 mm | 1.14 in | 222 mm | 84 % | Enclosed | 70 °C | -20 °C | CE cURus TUV | 30 V | 75 W | Chassis Mount | 3000 V | 1 |
Cosel USA, Inc. | Adjustable Output PFC Universal Input | ITE (Commercial) | 2.5 A | 55 mm | 8.74 in | 2.17 " | 29 mm | 1.14 in | 222 mm | 84 % | Open Frame | 70 °C | -20 °C | CE cURus TUV | 30 V | 75 W | Chassis Mount | 3000 V | 1 |
Cosel USA, Inc. | Adjustable Output PFC Universal Input | ITE (Commercial) | 6.3 A | 55 mm | 8.74 in | 2.17 " | 29 mm | 1.14 in | 222 mm | 80 % | Enclosed | 70 °C | -20 °C | CE cURus TUV | 12 V | 75 W | Chassis Mount | 3000 V | 1 |
Cosel USA, Inc. | Adjustable Output PFC Remote On/Off Universal Input | ITE (Commercial) | 5 A | 55 mm | 8.74 in | 2.17 " | 29 mm | 1.14 in | 222 mm | 81 % | Open Frame | 70 °C | -20 °C | CE cURus TUV | 15 V | 75 W | Chassis Mount | 3000 V | 1 |
 Cosel USA, Inc. | Adjustable Output PFC Universal Input | ITE (Commercial) | 1.6 A | 55 mm | 8.74 in | 2.17 " | 29 mm | 1.14 in | 222 mm | 86 % | Open Frame | 70 °C | -20 °C | CE cURus TUV | 48 V | 75 W | Chassis Mount | 3000 V | 1 |
Cosel USA, Inc. | PFC Universal Input | ITE (Commercial) | 3.2 A | 55 mm | 8.74 in | 2.17 " | 29 mm | 1.14 in | 222 mm | 84 % | Open Frame Conformal Coated | 70 °C | -20 °C | CE cURus TUV | 24 V | 75 W | Chassis Mount | 3000 V | 1 |
Cosel USA, Inc. | PFC Universal Input | ITE (Commercial) | 3.2 A | 55 mm | 8.74 in | 2.17 " | 29 mm | 1.14 in | 222 mm | 84 % | Enclosed | 70 °C | -20 °C | CE cURus TUV | 24 V | 75 W | Chassis Mount | 3000 V | 1 |
Cosel USA, Inc. | PFC Remote On/Off Universal Input | ITE (Commercial) | 3.2 A | 55 mm | 8.74 in | 2.17 " | 29 mm | 1.14 in | 222 mm | 84 % | Open Frame | 70 °C | -20 °C | CE cURus TUV | 24 V | 75 W | Chassis Mount | 3000 V | 1 |
