307-041 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 82POS 0.156
| Part | Material - Insulation | Termination Rows | Number of Positions/Bay/Row | Read Out | Number of Positions | Color | Contact Type | Number of Rows [custom] | Contact Finish | Card Type | Gender | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Flange Feature | Mounting Type | Termination | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | 41 | Dual | 82 | Green | Semi Bellows | 2 | Tin | Non Specified - Dual Edge | Female | Copper Alloy | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | ||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 41 | Dual | 82 | Green | Semi Bellows | 2 | Gold | Non Specified - Dual Edge | Female | Copper Alloy | -40 C | 105 ░C | Flush Mount Side Opening Unthreaded | Surface Mount | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 41 | Single | 41 | Green | Semi Bellows | Tin | Non Specified - Single Edge | Female | Copper Alloy | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 1 | Card Guides | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 41 | Single | 41 | Green | Semi Bellows | Tin | Non Specified - Single Edge | Female | Copper Alloy | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 1 | ||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 41 | Dual | 82 | Green | Semi Bellows | 2 | Gold | Non Specified - Dual Edge | Female | Copper Alloy | -40 C | 105 ░C | Flush Mount M3 Threaded Insert Top Opening | Surface Mount | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 41 | Single | 41 | Green | Semi Bellows | Tin | Non Specified - Single Edge | Female | Copper Alloy | -40 C | 105 ░C | Flush Mount M3 Threaded Insert Top Opening | Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 1 | ||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 41 | Single | 41 | Green | Semi Bellows | Tin | Non Specified - Single Edge | Female | Copper Alloy | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 0.156 " | 3.96 mm | 1 | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 41 | Dual | 82 | Green | Semi Bellows | 2 | Tin | Non Specified - Dual Edge | Female | Copper Alloy | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | Right Angle Through Hole | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 0.128 " | 3.25 mm | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 41 | Single | 41 | Green | Semi Bellows | Tin | Non Specified - Single Edge | Female | Copper Alloy | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | Through Hole | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 0.156 " | 3.96 mm | 1 | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 41 | Single | 41 | Green | Semi Bellows | Gold | Non Specified - Single Edge | Female | Copper Alloy | -40 C | 105 ░C | Flush Mount Side Opening Unthreaded | Through Hole | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | 1 |
