627-M15 Series
Manufacturer: EDAC Inc.
Beta
⌘K
D-SUB STANDARD CONNECTORS VERTICAL MACHINED D-SUB CONNECTORS
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Color | Dielectric Material | Termination | Material Flammability Rating | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Shell Size, Connector Layout | Features | Shell Material, Finish | Flange Feature | Current Rating (Amps) | Mounting Type | Connector Style | Connector Type | Contact Finish | Contact Type | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Black | Polyamide (PA6T) Nylon 6T | Solder | UL94 V-0 | 2 | 0.38 µm | 15 µin | 15 | 2 | Board Lock Grounding Indents Shielded | Nickel Plated Steel | Board Side (4-40) | 5 A | Through Hole | D-Sub | Plug Male Pins | Gold | Signal | |
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Green | Polyamide (PA6T) Nylon 6T | Solder | UL94 V-0 | 2 | 15 | 2 | Board Lock Grounding Indents Shielded | Board Side (4-40) | 5 A | Through Hole | D-Sub | Plug Male Pins | Gold | Signal | Flash | |||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | White | Polyamide (PA6T) Nylon 6T | Solder | UL94 V-0 | 2 | 15 | 2 | Board Lock Grounding Indents Shielded | Nickel Plated Steel | Board Side (4-40) | 5 A | Through Hole | D-Sub | Plug Male Pins | Gold | Signal | Flash | ||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | White | Polyamide (PA6T) Nylon 6T | Solder | UL94 V-0 | 2 | 0.38 µm | 15 µin | 15 | 2 | Grounding Indents Shielded | Nickel Plated Steel | Board Side (4-40) | 5 A | Through Hole | D-Sub | Plug Male Pins | Gold | Signal | |
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | White | Polyamide (PA6T) Nylon 6T | Solder | UL94 V-0 | 2 | 0.38 µm | 15 µin | 15 | 2 | Grounding Indents Shielded | Nickel Plated Steel | Board Side (4-40) | 5 A | Through Hole | D-Sub | Plug Male Pins | Gold | Signal | |
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Green | Polyamide (PA6T) Nylon 6T | UL94 V-0 | 2 | 0.76 Ám | 30 Áin | 15 | 2 | Grounding Indents Shielded | Nickel Plated Steel | Board Side (4-40) | 5 A | Free Hanging (In-Line) | D-Sub | Plug Male Pins | Gold | Signal | ||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Black | Polyamide (PA6T) Nylon 6T | Solder | UL94 V-0 | 2 | 0.38 µm | 15 µin | 15 | 2 | Grounding Indents Shielded | Nickel Plated Steel | Board Side (4-40) | 5 A | Through Hole | D-Sub | Plug Male Pins | Gold | Signal | |
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Blue | Polyamide (PA6T) Nylon 6T | Solder | UL94 V-0 | 2 | 0.38 µm | 15 µin | 15 | 2 | Board Lock Grounding Indents Shielded | Nickel Plated Steel | Board Side (4-40) | 5 A | Through Hole | D-Sub | Plug Male Pins | Gold | Signal | |
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | White | Polyamide (PA6T) Nylon 6T | UL94 V-0 | 2 | 0.38 µm | 15 µin | 15 | 2 | Grounding Indents Shielded | Board Side (4-40) | 5 A | Free Hanging (In-Line) | D-Sub | Plug Male Pins | Gold | Signal | |||
 EDAC Inc. | -55 C | 125 °C | Copper Alloy | Black | Polyamide (PA6T) Nylon 6T | Solder | UL94 V-0 | 2 | 0.38 µm | 15 µin | 15 | 2 | Grounding Indents Shielded | Board Side (4-40) | 5 A | Through Hole | D-Sub | Plug Male Pins | Gold | Signal |
