307-031 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 62POS 0.156
| Part | Termination Rows | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Color | Contact Finish | Number of Positions/Bay/Row [custom] | Contact Type | Number of Positions | Flange Feature | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Features | Read Out | Card Type | Mounting Type | Gender | Contact Material | Number of Rows [custom] | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Number of Positions [custom] | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Tin | 31 | Semi Bellows | 62 | 4-40 Flush Mount Threaded Insert Top Opening | Solder Eyelet(s) | -40 C | 105 ░C | Card Guides | Dual | Non Specified - Dual Edge | Through Hole | Female | Copper Alloy | 2 | 3.96 mm | 0.156 in | ||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Gold | 31 | Semi Bellows | 62 | 4-40 Flush Mount Threaded Insert Top Opening | Solder | -40 C | 105 ░C | Card Guides | Dual | Non Specified - Dual Edge | Right Angle Through Hole | Female | Copper Alloy | 2 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Gold | 31 | Semi Bellows | 62 | 4-40 Flush Mount Threaded Insert Top Opening | Wire Wrap | -40 C | 105 ░C | Card Guides | Dual | Non Specified - Dual Edge | Through Hole | Female | Copper Alloy | 2 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Tin | 31 | Semi Bellows | Solder | -40 C | 105 ░C | Single | Non Specified - Single Edge | Through Hole | Female | Copper Alloy | 3.96 mm | 0.156 in | 1 | 31 | ||||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Tin | 31 | Semi Bellows | Flush Mount Top Opening Unthreaded | Solder Eyelet(s) | -40 C | 105 ░C | Single | Non Specified - Single Edge | Through Hole | Female | Copper Alloy | 3.96 mm | 0.156 in | 1 | 31 | 0.156 " | 3.96 mm | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Tin | 31 | Semi Bellows | 62 | 4-40 Flush Mount Threaded Insert Top Opening | Solder | -40 C | 105 ░C | Dual | Non Specified - Dual Edge | Through Hole | Female | Copper Alloy | 2 | 3.96 mm | 0.156 in | |||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Tin | 31 | Semi Bellows | Flush Mount Top Opening Unthreaded | Solder | -40 C | 105 ░C | Single | Non Specified - Single Edge | Through Hole | Female | Copper Alloy | 3.96 mm | 0.156 in | 1 | 31 | 0.128 " | 3.25 mm | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Tin | 31 | Semi Bellows | 62 | Flush Mount Side Opening Unthreaded | Solder | -40 C | 105 ░C | Dual | Non Specified - Dual Edge | Through Hole | Female | Copper Alloy | 2 | 3.96 mm | 0.156 in | 0.128 " | 3.25 mm | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Tin | 31 | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | Solder | -40 C | 105 ░C | Single | Non Specified - Single Edge | Right Angle Through Hole | Female | Copper Alloy | 3.96 mm | 0.156 in | 1 | 31 | |||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Gold | 31 | Semi Bellows | 62 | Flush Mount Top Opening Unthreaded | Solder | -40 C | 105 ░C | Dual | Non Specified - Dual Edge | Through Hole | Female | Copper Alloy | 2 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm |
