3257 Series

Catalog

CONN TERM RECT 250 MCM

Part	Diameter - Barrel OD [diameter]	Diameter - Barrel OD [diameter]	Termination	Insulation	Terminal Type	Wire Gauge	Wire Gauge	Width - Outer Edges [y]	Width - Outer Edges [y]	Contact Material	Contact Finish	Diameter - Barrel ID [diameter]	Diameter - Barrel ID [diameter]	Terminal Style	Length - Overall [x]	Length - Overall [x]	Tab Thickness	Tab Thickness	Mounting Type	Stud/Tab Size	Diameter - Ring ID [diameter]	Diameter - Ring ID [diameter]
TE Connectivity Raychem Cable Protection 325708	22.12 mm	0.871 in	Barrel Crimp	Non-Insulated	Standard	250 kcmil	250 MCM	32.51 mm	1.28 in	Copper	Tin	0.69 in	17.53 mm	No Stud Hole	73.41 mm	2.89 in	3.81 mm	0.15 "	Free Hanging (In-Line)
TE Connectivity Raychem Cable Protection 325719	26.67 mm	1.05 "	Barrel Crimp	Non-Insulated	Rectangular Tongue	250 kcmil	250 MCM	32.51 mm	1.28 in	Copper	Tin	0.7 in	17.78 mm	No Stud Hole	143 mm	5.63 in	3.81 mm	0.15 "	Free Hanging (In-Line)
TE Connectivity Raychem Cable Protection 325702	22.12 mm	0.871 in	Barrel Crimp	Non-Insulated	Standard	250 kcmil	250 MCM	32.51 mm	1.28 in	Copper	Tin	0.69 in	17.53 mm	Single Stud Hole	65.53 mm	2.58 in	3.81 mm	0.15 "	Free Hanging (In-Line)	0.3125 Stud	8.33 mm	0.328 in
