698MHz-2.7GHz Cellular Ceramic Antenna, SMT
698MHz-2.7GHz Cellular Ceramic Antenna, SMT
| Part | Frequency Group | Number of Bands | Antenna Type | Frequency (Center/Band) | Gain | Height (Max) [Max] [z] | Height (Max) [Max] [z] | Mounting Type | Power - Max [Max] | Termination | RF Family/Standard | Return Loss | Applications | Frequency Range [Max] | Frequency Range [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Wide Band | 2 | Chip | 829 MHz 2200 GHz | 4.5 dBic | 0.197 in | 5 mm | Surface Mount | 2 W | Solder | Cellular | -5 dB | LTE | 2.7 GHz 960 MHz | 1.71 GHz 698 MHz |
 Molex | Wide Band | 2 | Ceramic Patch | 2.205 GHz 829 MHz | 0.5 dBi 3.7 dBi | 0.197 in | 5 mm | Surface Mount | Solder | Cellular | -5 dB | LTE | 2.7 GHz 960 MHz | 1.71 GHz 698 MHz |
