396-044 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 44POS 0.125
| Part | Material - Insulation | Termination Rows | Contact Finish | Pitch | Pitch | Number of Positions/Bay/Row | Number of Rows | Number of Positions | Contact Type | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Flange Feature | Contact Material | Card Type | Color | Contact Finish Thickness | Contact Finish Thickness | Gender | Mounting Type | Read Out | Card Thickness [Max] | Card Thickness [Min] | Termination Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | 3.18 mm | 0.125 in | 44 | 1 | 44 | Cantilever | Solder Wire Wrap | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Non Specified - Single Edge | Black | 0.25 Ám | 10 Áin | Female | Right Angle Through Hole | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||||
 EDAC Inc. | Polyester Thermoplastic | Gold | 3.18 mm | 0.125 in | 22 | 44 | Cantilever | Solder | -40 C | 105 ░C | Side Mount Opening Unthreaded | Copper Alloy | Non Specified - Dual Edge | Black | 0.25 Ám | 10 Áin | Female | Through Hole | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 0.128 " | 3.25 mm | 2 | |||
 EDAC Inc. | Polyester Thermoplastic | Gold | 3.18 mm | 0.125 in | 22 | 44 | Cantilever | Solder | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | Copper Alloy | Non Specified - Dual Edge | Black | 0.25 Ám | 10 Áin | Female | Through Hole | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 0.156 " | 3.96 mm | 2 | |||
 EDAC Inc. | Polyester Thermoplastic | Gold | 3.18 mm | 0.125 in | 22 | 44 | Cantilever | Solder Wire Wrap | -40 C | 105 ░C | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | Non Specified - Dual Edge | Black | 0.25 Ám | 10 Áin | Female | Right Angle Through Hole | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 2 | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | 3.18 mm | 0.125 in | 44 | 1 | 44 | Cantilever | Wire Wrap | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Non Specified - Single Edge | Black | 0.25 Ám | 10 Áin | Female | Through Hole | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | 3.18 mm | 0.125 in | 44 | 1 | 44 | Cantilever | Solder | -40 C | 105 ░C | Flush Mount Side Opening Unthreaded | Copper Alloy | Non Specified - Single Edge | Black | 0.25 Ám | 10 Áin | Female | Through Hole | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | 3.18 mm | 0.125 in | 44 | 1 | 44 | Cantilever | Solder | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Non Specified - Single Edge | Black | 0.25 Ám | 10 Áin | Female | Through Hole | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | Gold | 3.18 mm | 0.125 in | 22 | 44 | Cantilever | Solder Wire Wrap | -40 C | 105 ░C | Copper Alloy | Non Specified - Dual Edge | Black | 0.25 Ám | 10 Áin | Female | Right Angle Through Hole | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 0.156 " | 3.96 mm | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | 3.18 mm | 0.125 in | 44 | 1 | 44 | Cantilever | Solder Wire Wrap | -40 C | 105 ░C | Copper Alloy | Non Specified - Single Edge | Black | 0.25 Ám | 10 Áin | Female | Right Angle Through Hole | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Gold | 3.18 mm | 0.125 in | 44 | 1 | 44 | Cantilever | Solder Wire Wrap | -40 C | 105 ░C | Copper Alloy | Non Specified - Single Edge | Black | 0.25 Ám | 10 Áin | Female | Right Angle Through Hole | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm |
