M80-700 Series
Manufacturer: Harwin Inc.
Beta
⌘K
PIN HEADER, BOARD-TO-BOARD, WIRE-TO-BOARD, 2 MM, 3 ROWS, 45 CONTACTS, THROUGH HOLE
| Part | Contact Finish Thickness - Post [custom] | Contact Finish Thickness - Post [custom] | Number of Positions Loaded | Current Rating (Amps) | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] | Voltage Rating | Connector Type | Mounting Type | Material Flammability Rating | Number of Rows [custom] | Number of Positions | Contact Type | Contact Finish - Mating | Contact Material | Contact Finish - Post | Insulation Color | Termination | Row Spacing - Mating | Row Spacing - Mating | Insulation Material | Style | Features | Shrouding | Fastening Type | Insulation Height | Insulation Height | Contact Length - Post | Contact Length - Post | Operating Temperature [Min] | Operating Temperature [Max] | Pitch - Mating | Pitch - Mating | Contact Shape | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Harwin Inc. | 118.1 µin | 3 µm | All | 2.2 A | 29.5 µin | 0.75 µm | 120 VDC | Header | Through Hole | UL94 V-0 | 3 | 45 | Male Pin | Gold | Phosphor Bronze | Tin | Black | Solder | 2 mm | 0.079 in | Nylon 4/6 Polyamide (PA46) | Board to Board Cable | Mating Flange Mounting Flange Mounting Hardware | Shrouded - 4 Wall | Threaded | 0.244 in | 6.2 mm | 0.118 in | 3 mm | -55 C | 125 °C | 0.079 " | 2 mm | Circular | ||||
 Harwin Inc. | All | 2.2 A | 120 VDC | Header | Through Hole | UL94 V-0 | 3 | 45 | Male Pin | Gold | Phosphor Bronze | Gold | Black | Solder | 2 mm | 0.079 in | Nylon 4/6 Polyamide (PA46) | Board to Board Cable | Mating Flange Mounting Flange Mounting Hardware | Shrouded - 4 Wall | Threaded | 0.244 in | 6.2 mm | 0.118 in | 3 mm | -55 C | 125 °C | 0.079 " | 2 mm | Circular | 10 Áin | 0.25 çm | 0.25 µm | 10 µin | ||||
 Harwin Inc. | 118.1 µin | 3 µm | All | 2.2 A | 29.5 µin | 0.75 µm | 120 VDC | Header | Through Hole | UL94 V-0 | 3 | 51 | Male Pin | Gold | Phosphor Bronze | Tin | Black | Solder | 2 mm | 0.079 in | Nylon 4/6 Polyamide (PA46) | Board to Board Cable | Mating Flange Mounting Flange Mounting Hardware | Shrouded - 4 Wall | Threaded | 0.244 in | 6.2 mm | 0.118 in | 3 mm | -55 C | 125 °C | 0.079 " | 2 mm | Circular | ||||
 Harwin Inc. | 118.1 µin | 3 µm | All | 2.2 A | 29.5 µin | 0.75 µm | 120 VDC | Header | Through Hole | UL94 V-0 | 3 | 51 | Male Pin | Gold | Phosphor Bronze | Tin-Lead | Black | Solder | 2 mm | 0.079 in | Nylon 4/6 Polyamide (PA46) | Board to Board Cable | Mating Flange Mounting Flange Mounting Hardware | Shrouded - 4 Wall | Threaded | 0.244 in | 6.2 mm | 0.118 in | 3 mm | -55 C | 125 °C | 0.079 " | 2 mm | Circular | ||||
Harwin Inc. | 118.1 µin | 3 µm | All | 2.2 A | 29.5 µin | 0.75 µm | 120 VDC | Header | Through Hole | UL94 V-0 | 3 | 27 | Male Pin | Gold | Phosphor Bronze | Tin | Black | Solder | 2 mm | 0.079 in | Nylon 4/6 Polyamide (PA46) | Board to Board Cable | Mating Flange Mounting Flange Mounting Hardware | Shrouded - 4 Wall | Threaded | 0.244 in | 6.2 mm | 0.118 in | 3 mm | -55 C | 125 °C | 0.079 " | 2 mm | Circular |
