R22294 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
SMP / STRAIGHT MALE RECEPTACLE S
| Part | Center Contact Plating | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Body Material | Body Finish | Voltage Rating | Impedance | Number of Ports | Mounting Type | Features | Center Contact Material | Housing Color | Frequency - Max [Max] | Contact Termination | Connector Type | Shield Termination | Fastening Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | Gold | Polyetheretherketone (PEEK) | -55 C | 125 °C | Brass | Gold | 335 V | 50 Ohms | 1 | Surface Mount | Full Detent | Brass | Gold | 12.4 GHz | Solder | Receptacle Male Pin | Solder | Snap-On |
 Radiall USA, Inc. | Gold | Polyetheretherketone (PEEK) | -55 C | 125 °C | Bronze | Gold | 335 V | 50 Ohms | 1 | Surface Mount | Limited Detent Non-Magnetic | Beryllium Copper | Gold | 12.4 GHz | Solder | Receptacle Male Pin | Solder | Snap-On |
 Radiall USA, Inc. | Gold | Polyetheretherketone (PEEK) | -55 C | 125 °C | Brass | Gold | 335 V | 50 Ohms | 1 | Through Hole | Full Detent | Brass | Gold | 12.4 GHz | Solder | Receptacle Male Pin | Solder | Snap-On |
 Radiall USA, Inc. | Gold | Polyetheretherketone (PEEK) | -55 C | 125 °C | Brass | Gold | 335 V | 50 Ohms | 1 | Surface Mount | Full Detent | Brass | Gold | 12.4 GHz | Solder | Receptacle Male Pin | Solder | Snap-On |
 Radiall USA, Inc. | Gold | Polyetheretherketone (PEEK) | -55 C | 125 °C | Brass | Gold | 335 V | 50 Ohms | 1 | Through Hole | Limited Detent | Brass | Gold | 12.4 GHz | Solder | Receptacle Male Pin | Solder | Snap-On |
 Radiall USA, Inc. | Gold | Polyetheretherketone (PEEK) | -55 C | 125 °C | Brass | Gold | 335 V | 50 Ohms | 1 | Surface Mount | Limited Detent | Brass | Gold | 12.4 GHz | Solder | Receptacle Male Pin | Solder | Snap-On |
 Radiall USA, Inc. | Gold | Polyetheretherketone (PEEK) | -55 C | 125 °C | Brass | Gold | 335 V | 50 Ohms | 1 | Through Hole | Full Detent | Brass | Gold | 12.4 GHz | Solder | Receptacle Male Pin | Solder | Snap-On |
 Radiall USA, Inc. | Gold | Polyetheretherketone (PEEK) | -55 C | 125 °C | Brass | Gold | 335 V | 50 Ohms | 1 | Surface Mount | Smooth Bore | Brass | Gold | 12.4 GHz | Solder | Receptacle Male Pin | Solder | Snap-On |
 Radiall USA, Inc. | Gold | Polytetrafluoroethylene (PTFE) | -55 C | 125 °C | Bronze | Gold | 50 Ohms | 1 | Through Hole | Limited Detent | Bronze | Gold | 12 GHz | Solder | Female Socket Jack | Solder |
