395-006 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 6POS 0.100
| Part | Material - Insulation | Termination Rows | Pitch | Pitch | Operating Temperature [Min] | Operating Temperature [Max] | Color | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Card Type | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Number of Positions/Bay/Row | Termination | Number of Positions | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows | Read Out | Gender | Contact Finish | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.1 " | 2.54 mm | -40 C | 105 ░C | Black | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 6 | Wire Wrap | 6 | 3.25 mm | 0.128 " | 1 | Single | Female | Gold | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.1 " | 2.54 mm | -40 C | 105 ░C | Black | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 6 | Solder | 6 | 3.25 mm | 0.128 " | 1 | Single | Female | Gold | Side Mount Opening Unthreaded | |
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.1 " | 2.54 mm | -40 C | 105 ░C | Black | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 6 | Solder | 6 | 1 | Single | Female | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.1 " | 2.54 mm | -40 C | 105 ░C | Black | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 6 | Wire Wrap | 6 | 3.96 mm | 0.156 " | 1 | Single | Female | Gold | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.1 " | 2.54 mm | -40 C | 105 ░C | Black | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 6 | Solder | 6 | 1 | Single | Female | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.1 " | 2.54 mm | -40 C | 105 ░C | Black | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 6 | Solder | 6 | 1 | Single | Female | Gold | 4-40 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.1 " | 2.54 mm | -40 C | 105 ░C | Black | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 6 | Solder | 6 | 1 | Single | Female | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.1 " | 2.54 mm | -40 C | 105 ░C | Black | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 6 | Wire Wrap | 6 | 1 | Single | Female | Gold | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.1 " | 2.54 mm | -40 C | 105 ░C | Black | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 6 | Solder | 6 | 1 | Single | Female | Gold | M3 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.1 " | 2.54 mm | -40 C | 105 ░C | Black | 0.25 Ám | 10 Áin | Cantilever | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 6 | Solder | 6 | 1 | Single | Female | Gold | 4-40 Threaded Insert Top Mount Opening |
