1.50mm Pitch, CLIK-Mate PCB Receptacle, Single Row, Through Hole, Right-Angle, Tin Plating, Positive Lock, with Peg, 15 Circuits, Black
1.50mm Pitch, CLIK-Mate PCB Receptacle, Single Row, Through Hole, Right-Angle, Tin Plating, Positive Lock, with Peg, 15 Circuits, Black
1.50mm Pitch, CLIK-Mate PCB Receptacle, Single Row, Through Hole, Right-Angle, Tin Plating, Positive Lock, with Peg, 15 Circuits, Black
| Part | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Contact Shape | Contact Type | Insulation Color | Connector Type | Voltage Rating | Termination | Number of Rows | Number of Positions Loaded | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Style | Insulation Material | Contact Length - Post [x] | Contact Length - Post [x] | Mounting Type | Contact Material | Current Rating (Amps) | Insulation Height | Insulation Height | Material Flammability Rating | Fastening Type | Contact Finish - Post | Features | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | 1 çm | 39.4 çin | -40 °C | 105 ░C | 15 | Rectangular | Forked | Beige | Receptacle | 100 VAC | Kinked Pin Solder | 1 | All | 1 µm | 39.4 µin | Board to Cable/Wire | Nylon Polyamide (PA) | 0.134 in | 3.4 mm | Through Hole Right Angle | Copper Alloy | Varies by Wire Gauge | 6.95 mm | 0.274 in | UL94 V-0 | Detent Lock | Tin | ||
Molex | 1 çm | 39.4 çin | -40 °C | 105 ░C | 10 | Rectangular | Forked | Beige | Receptacle | 100 VAC | Kinked Pin Solder | 1 | All | 1 µm | 39.4 µin | Board to Cable/Wire | Nylon Polyamide (PA) | 0.134 in | 3.4 mm | Through Hole Right Angle | Copper Alloy | Varies by Wire Gauge | 6.95 mm | 0.274 in | UL94 V-0 | Detent Lock | Tin | ||
 Molex | 1 çm | 39.4 çin | -40 °C | 105 ░C | 9 | Forked | Beige | Receptacle | Kinked Pin Solder | 1 | All | 1 µm | 39.4 µin | Board to Cable/Wire | Nylon Polyamide (PA) | 0.134 in | 3.4 mm | Through Hole Right Angle | Copper Alloy | 6.95 mm | 0.274 in | UL94 V-0 | Latch Holder | Tin | Board Guide | Automotive General Purpose Industrial Lighting Medical | |||
 Molex | 1 çm | 39.4 çin | -40 °C | 105 ░C | 15 | Rectangular | Forked | Red | Receptacle | 100 VAC | Kinked Pin Solder | 1 | All | 1 µm | 39.4 µin | Board to Cable/Wire | Nylon Polyamide (PA) | 0.134 in | 3.4 mm | Through Hole Right Angle | Copper Alloy | Varies by Wire Gauge | 6.95 mm | 0.274 in | UL94 V-0 | Detent Lock | Tin | Board Guide | |
Molex | |||||||||||||||||||||||||||||
Molex | 1 çm | 39.4 çin | -40 °C | 105 ░C | 7 | Forked | Beige | Receptacle | Kinked Pin Solder | 1 | All | 1 µm | 39.4 µin | Board to Cable/Wire | Nylon Polyamide (PA) | 0.134 in | 3.4 mm | Through Hole Right Angle | Copper Alloy | 6.95 mm | 0.274 in | UL94 V-0 | Latch Holder | Tin | Board Guide | Automotive General Purpose Industrial Lighting Medical | |||
Molex | 1 çm | 39.4 çin | 12 | Square | Outer Shroud Contact | Red | Receptacle | Kinked Pin Solder | 1 | All | 1 µm | 39.4 µin | Board to Board Cable | Nylon Polyamide (PA) | 0.134 in | 3.4 mm | Through Hole | Copper Alloy | 6.95 mm | 0.274 in | UL94 V-0 | Push-Pull | Tin | Board Guide | |||||
 Molex | 1 çm | 39.4 çin | -40 °C | 105 ░C | 13 | Forked | Natural | Receptacle | 100 VAC | Kinked Pin Solder | 1 | All | 1 µm | 39.4 µin | Board to Cable/Wire | Nylon Polyamide (PA) | 0.134 in | 3.4 mm | Through Hole Right Angle | Copper Alloy | Varies by Wire Gauge | 6.95 mm | 0.274 in | UL94 V-0 | Latch Holder | Tin | Automotive General Purpose Industrial Lighting Medical | ||
 Molex | 1 çm | 39.4 çin | -40 °C | 105 ░C | Rectangular | Forked | Beige | Receptacle | 100 VAC | Kinked Pin Solder | 1 | All | 1 µm | 39.4 µin | Board to Cable/Wire | Nylon Polyamide (PA) | 0.134 in | 3.4 mm | Through Hole Right Angle | Copper Alloy | Varies by Wire Gauge | 6.95 mm | 0.274 in | UL94 V-0 | Detent Lock | Tin | |||
 Molex | 1 çm | 39.4 çin | -40 °C | 105 ░C | 6 | Forked | Red | Receptacle | 100 VAC | Kinked Pin Solder | 1 | All | 1 µm | 39.4 µin | Board to Cable/Wire | Nylon Polyamide (PA) | 0.134 in | 3.4 mm | Through Hole Right Angle | Copper Alloy | Varies by Wire Gauge | 6.95 mm | 0.274 in | UL94 V-0 | Latch Holder | Tin | Board Guide | Automotive General Purpose Industrial Lighting Medical |
