842-037 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 37POS 0.100
| Part | Material - Insulation | Termination Rows | Contact Type | Color | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Termination | Mounting Type | Gender | Card Type | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Number of Rows | Number of Positions/Bay/Row | Contact Material | Number of Positions | Read Out | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | 125 °C | -40 C | 0.1 " | 2.54 mm | Solder | Right Angle Through Hole | Female | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 37 | Copper Alloy | 37 | Single | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | 125 °C | -40 C | 0.1 " | 2.54 mm | Wire Wrap | Through Hole | Female | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 37 | Copper Alloy | 37 | Single | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | 125 °C | -40 C | 0.1 " | 2.54 mm | Wire Wrap | Through Hole | Female | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 37 | Copper Alloy | 37 | Single | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | 125 °C | -40 C | 0.1 " | 2.54 mm | Solder | Through Hole | Female | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 37 | Copper Alloy | 37 | Single | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | 125 °C | -40 C | 0.1 " | 2.54 mm | Solder | Right Angle Through Hole | Female | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 37 | Copper Alloy | 37 | Single | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | 125 °C | -40 C | 0.1 " | 2.54 mm | Solder | Through Hole | Female | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 37 | Copper Alloy | 37 | Single | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | 125 °C | -40 C | 0.1 " | 2.54 mm | Solder | Right Angle Through Hole | Female | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 37 | Copper Alloy | 37 | Single | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | 125 °C | -40 C | 0.1 " | 2.54 mm | Wire Wrap | Through Hole | Female | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 37 | Copper Alloy | 37 | Single | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | 125 °C | -40 C | 0.1 " | 2.54 mm | Wire Wrap | Through Hole | Female | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 37 | Copper Alloy | 37 | Single | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | 125 °C | -40 C | 0.1 " | 2.54 mm | Solder | Right Angle Through Hole | Female | Non Specified - Single Edge | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 37 | Copper Alloy | 37 | Single | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin |
