2SA1579 Series

Catalog

PNP, SOT-323, -120V -50MA, HIGH-VOLTAGE AMPLIFIER TRANSISTOR

Part	Power - Max [Max]	Current - Collector (Ic) (Max) [Max]	Transistor Type	Mounting Type	Voltage - Collector Emitter Breakdown (Max) [Max]	Operating Temperature	Package / Case	Current - Collector Cutoff (Max) [Max]	Frequency - Transition	DC Current Gain (hFE) (Min) @ Ic, Vce [Min]	Supplier Device Package	Vce Saturation (Max) @ Ib, Ic
Rohm Semiconductor 2SA1579U3T106	200 mW	50 mA	PNP	Surface Mount	120 V	150 °C	SC-70 SOT-323	500 nA	140 MHz	180	UMT3
Rohm Semiconductor 2SA1579U3T106R	200 mW	50 mA	NPN PNP	Surface Mount	120 V	150 °C	SC-70 SOT-323	500 nA		180	UMT3	250 mV
Rohm Semiconductor 2SA1579T106S	200 mW	50 mA	PNP	Surface Mount	120 V	150 °C	SC-70 SOT-323	500 nA	140 MHz	180	UMT3
Rohm Semiconductor 2SA1579T106R	200 mW	50 mA	PNP	Surface Mount	120 V	150 °C	SC-70 SOT-323	500 nA	140 MHz	180	UMT3
