RT-780 Series

Manufacturer: TE Connectivity Aerospace, Defense and Marine

Catalog

RT-780-1-1/2-3-SP

Part	Inner Diameter - Supplied [diameter]	Inner Diameter - Supplied [diameter]	Recovered Wall Thickness	Recovered Wall Thickness	Inner Diameter - Recovered [diameter]	Inner Diameter - Recovered [diameter]	Operating Temperature [Min]	Operating Temperature [Max]	Material	Shrinkage Ratio	Shrink Temperature	Type	Features	Inner Diameter - Recovered	Color	Spool Size	Spool Size	Length	Length	Length	Recovered Wall Thickness	Inner Diameter - Recovered
TE Connectivity Aerospace, Defense and Marine RT-780-1-1/2-3-SP	38.1 mm	1.5 in	0.045 in	1.14 mm	19.05 mm	0.75 "	-55 °C	347 °F	Fluoroelastomer (FKM)	2 to 1	175 °C	Tubing Flexible	Chemical Resistant Flame Resistant Fluid Resistant
TE Connectivity Aerospace, Defense and Marine RT-780-1/4-0-SP	6.35 mm	0.25 in	0.018 in	0.46 mm		0.125 in	-55 °C	347 °F	Fluoroelastomer (FKM) Irradiated	2 to 1	175 °C	Tubing Flexible	Chemical Resistant Flame Resistant Fluid Resistant	3.18 mm	Black
TE Connectivity Aerospace, Defense and Marine RT-780-3/4-0-SP			0.032 "	0.81 mm	9.53 mm	0.375 in			Fluoropolymer	2 to 1	180 °C	Tubing Flexible	Chemical Resistant		Black	76.2 m	250 ft	Enter Number of Feet in Order Quantity
TE Connectivity Aerospace, Defense and Marine RT-780-1/8-0-SP	3.18 mm	0.125 "	0.014 "	0.36 mm	1.57 mm	0.062 in			Fluoropolymer	2 to 1	180 °C	Tubing Flexible	Chemical Resistant		Black				1500 '	457.2 m
TE Connectivity Aerospace, Defense and Marine RT-780-2-0-SP	50.8 mm	2 in		0.048 in	25.4 mm	1 in	-55 °C	347 °F	Fluoroelastomer (FKM)	2 to 1	175 °C	Tubing Flexible	Chemical Resistant Flame Resistant Fluid Resistant		Black						1.22 mm
TE Connectivity Aerospace, Defense and Marine RT-780-1-0-SP	25.4 mm	1 in	0.037 in	0.94 mm	12.7 mm	0.5 in	-55 °C	347 °F	Fluoroelastomer (FKM)	2 to 1	175 °C	Tubing Flexible	Chemical Resistant Flame Resistant Fluid Resistant		Black
TE Connectivity Aerospace, Defense and Marine RT-780-3/16-0-SP	4.75 mm	0.187 in	0.016 "	0.41 mm					Fluoropolymer	2 to 1	180 °C	Tubing Flexible	Chemical Resistant	2.36 mm	Black							0.093 in
TE Connectivity Aerospace, Defense and Marine RT-780-1-1/4-0-SP	31.75 mm	1.25 in	0.04 in	1.02 mm	15.88 mm	0.625 in	-55 °C	347 °F	Fluoroelastomer (FKM) Irradiated	2 to 1	175 °C	Tubing Flexible	Chemical Resistant Flame Resistant Fluid Resistant		Black
TE Connectivity Aerospace, Defense and Marine RT-780-3/4-3-SP			0.032 "	0.81 mm	9.53 mm	0.375 in	-55 °C	347 °F	Fluoroelastomer (FKM)	2 to 1	175 °C	Tubing Flexible	Chemical Resistant Flame Resistant Fluid Resistant
TE Connectivity Aerospace, Defense and Marine RT-780-5/8-0-SP	15.88 mm	0.625 in	0.026 "	0.66 mm	7.92 mm	0.312 in	-55 °C	347 °F	Fluoroelastomer (FKM) Irradiated	2 to 1	175 °C	Tubing Flexible	Chemical Resistant Flame Resistant Fluid Resistant		Black
