109E4712 Series

Catalog

FAN AXIAL 172X25.4MM 12VDC WIRE

Part	Air Flow	Air Flow	Current Rating (Amps)	Material - Frame	Material - Blade	Voltage Range [Min]	Voltage Range [Max]	Lifetime @ Temp.	RPM	Width [y]	Static Pressure	Static Pressure	Voltage - Rated	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension	Weight [custom]	Weight [custom]	Approval Agency	Fan Type	Noise	Features	Termination	Bearing Type	Operating Temperature [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Power (Watts)
Sanyo Denki America Inc. 109E4712M4D01	5.12 mł/min	183 CFM	1.3 A	Aluminum	Plastic	10.2 VDC	13.8 VDC	40000 Hrs	2800 RPM	25.4 mm	91.9 Pa	0.369 in H2O	12 VDC	172 mm	147 mm	Rectangular/Rounded	1.1 lbs	500 g	CSA TUV UL	Tubeaxial	51 dB(A)	Locked Rotor Sensor	3 Wire Leads	Ball	60 °C	60 °C	-4 °F	-20 ░C	15.6 W
Sanyo Denki America Inc. 109E4712L4D01	4.54 mł/min	162 CFM	1 A	Aluminum	Plastic	10.2 VDC	13.8 VDC	40000 Hrs	2500 RPM	25.4 mm	73 Pa	0.293 in H2O	12 VDC	172 mm	147 mm	Rectangular/Rounded	1.1 lbs	500 g	CSA TUV UL	Tubeaxial	48 dB	Locked Rotor Sensor	3 Wire Leads	Ball	60 °C	60 °C	-4 °F	-20 ░C	12 W
Sanyo Denki America Inc. 109E4712L401	4.54 mł/min	162 CFM	1 A	Aluminum	Plastic	10.2 VDC	13.8 VDC	40000 Hrs	2500 RPM	25.4 mm	73 Pa	0.293 in H2O	12 VDC	172 mm	147 mm	Rectangular/Rounded	1.1 lbs	500 g	CSA TUV UL	Tubeaxial	48 dB	Locked Rotor Protection Speed Sensor (Tach)	3 Wire Leads	Ball	60 °C	60 °C	-4 °F	-20 ░C	12 W
