807-035 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 70POS 0.156
| Part | Number of Positions | Pitch | Pitch | Color | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Read Out | Number of Rows [custom] | Contact Finish | Gender | Contact Material | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Contact Type | Termination Rows | Termination | Number of Positions/Bay/Row | Flange Feature | Material - Insulation | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 70 | 3.96 mm | 0.156 in | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Dual | 2 | Gold | Female | Copper Alloy | Non Specified - Dual Edge | 125 °C | -40 C | Semi Bellows | 1 | Solder | 35 | 4-40 Flush Mount Threaded Insert Top Opening | Diallyl Phthalate (DAP) | |||
 EDAC Inc. | 70 | 3.96 mm | 0.156 in | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Dual | 2 | Tin | Female | Copper Alloy | Non Specified - Dual Edge | 125 °C | -40 C | Semi Bellows | 1 | Solder Eyelet(s) | 35 | 4-40 Flush Mount Threaded Insert Top Opening | Diallyl Phthalate (DAP) | |||||
 EDAC Inc. | 70 | 3.96 mm | 0.156 in | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Dual | 2 | Tin | Female | Copper Alloy | Non Specified - Dual Edge | 125 °C | -40 C | Semi Bellows | 1 | Solder | 35 | Flush Mount M3 Threaded Insert Top Opening | Diallyl Phthalate (DAP) | |||||
 EDAC Inc. | 35 | 3.96 mm | 0.156 in | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Single | Gold | Female | Copper Alloy | Non Specified - Single Edge | 125 °C | -40 C | Semi Bellows | 1 | Wire Wrap | 35 | Floating Bobbin Flush Mount | Diallyl Phthalate (DAP) | 0.116 " | 2.95 mm | 1 | |
 EDAC Inc. | 35 | 3.96 mm | 0.156 in | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Single | Tin | Female | Copper Alloy | Non Specified - Single Edge | 125 °C | -40 C | Semi Bellows | 1 | Solder | 35 | Flush Mount Top Opening Unthreaded | Diallyl Phthalate (DAP) | 0.156 " | 3.96 mm | 1 | |||
 EDAC Inc. | 35 | 3.96 mm | 0.156 in | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Single | Tin | Female | Copper Alloy | Non Specified - Single Edge | 125 °C | -40 C | Semi Bellows | 1 | Solder | 35 | Floating Bobbin Flush Mount | Diallyl Phthalate (DAP) | 0.116 " | 2.95 mm | 1 | |||
 EDAC Inc. | 35 | 3.96 mm | 0.156 in | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Single | Tin | Female | Copper Alloy | Non Specified - Single Edge | 125 °C | -40 C | Semi Bellows | 1 | Solder | 35 | Flush Mount Top Opening Unthreaded | Diallyl Phthalate (DAP) | 0.128 " | 3.25 mm | 1 | |||
 EDAC Inc. | 35 | 3.96 mm | 0.156 in | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Single | Gold | Female | Copper Alloy | Non Specified - Single Edge | 125 °C | -40 C | Semi Bellows | 1 | Wire Wrap | 35 | Diallyl Phthalate (DAP) | 1 | ||||
 EDAC Inc. | 35 | 3.96 mm | 0.156 in | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Single | Tin | Female | Copper Alloy | Non Specified - Single Edge | 125 °C | -40 C | Semi Bellows | 1 | Solder | 35 | Flush Mount M3 Threaded Insert Top Opening | Diallyl Phthalate (DAP) | 1 | |||||
 EDAC Inc. | 70 | 3.96 mm | 0.156 in | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Dual | 2 | Gold | Female | Copper Alloy | Non Specified - Dual Edge | 125 °C | -40 C | Semi Bellows | 1 | Wire Wrap | 35 | Diallyl Phthalate (DAP) |
