1969543 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

(3-1969543-2) ASSY, HDR, VERT, BOSSED, DUAL ROW, EP2.5

Part	Number of Positions Loaded	Row Spacing - Mating	Row Spacing - Mating	Number of Rows	Style	Material Flammability Rating	Connector Type	Contact Shape	Insulation Height	Insulation Height	Mounting Type	Fastening Type	Voltage Rating	Shrouding	Applications	Features	Current Rating (Amps)	Contact Material	Pitch - Mating	Pitch - Mating	Insulation Material	Insulation Color	Operating Temperature [Max]	Operating Temperature [Min]	Contact Type	Termination	Contact Finish - Post	Contact Length - Post [x]	Contact Length - Post [x]	Number of Positions
TE Connectivity Raychem Cable Protection 3-1969543-2	All	0.098 in	2.5 mm	2	Board to Cable/Wire	UL94 V-0	Header	Circular	9.8 mm	0.386 in	Through Hole	Friction Lock	250 VAC	Shrouded - 4 Wall	General Purpose Industrial Lighting	Board Guide	4.2 A	Brass	2.5 mm	0.098 in	Polyamide (PA66) Nylon 6/6	White	105 ░C	-55 °C	Male Pin	Kinked Pin Solder	Tin	0.134 in	3.4 mm
TE Connectivity Raychem Cable Protection 4-1969543-0	All	0.098 in	2.5 mm	2	Board to Cable/Wire	UL94 V-0	Header	Circular	9.8 mm	0.386 in	Through Hole	Friction Lock	250 VAC	Shrouded - 4 Wall	General Purpose Industrial Lighting	Board Guide	4.2 A	Brass	2.5 mm	0.098 in	Polyamide (PA66) Nylon 6/6	White	105 ░C	-55 °C	Male Pin	Kinked Pin Solder	Tin	0.134 in	3.4 mm	40
TE Connectivity Raychem Cable Protection 1969543-8	All	0.098 in	2.5 mm	2	Board to Cable/Wire	UL94 V-0	Header	Circular	9.8 mm	0.386 in	Through Hole	Friction Lock	250 VAC	Shrouded - 4 Wall	General Purpose Industrial Lighting	Board Guide	4.2 A	Brass	2.5 mm	0.098 in	Polyamide (PA66) Nylon 6/6	White	105 ░C	-55 °C	Male Pin	Kinked Pin Solder	Tin	0.134 in	3.4 mm	8
TE Connectivity Raychem Cable Protection 3-1969543-6	All	0.098 in	2.5 mm	2	Board to Cable/Wire	UL94 V-0	Header	Circular	9.8 mm	0.386 in	Through Hole	Friction Lock	250 VAC	Shrouded - 4 Wall	General Purpose Industrial Lighting	Board Guide	4.2 A	Brass	2.5 mm	0.098 in	Polyamide (PA66) Nylon 6/6	White	105 ░C	-55 °C	Male Pin	Kinked Pin Solder	Tin	0.134 in	3.4 mm	36
TE Connectivity Raychem Cable Protection 1-1969543-0	All	0.098 in	2.5 mm	2	Board to Cable/Wire	UL94 V-0	Header	Circular	9.8 mm	0.386 in	Through Hole	Friction Lock	250 VAC	Shrouded - 4 Wall	General Purpose Industrial Lighting	Board Guide	4.2 A	Brass	2.5 mm	0.098 in	Polyamide (PA66) Nylon 6/6	White	105 ░C	-55 °C	Male Pin	Kinked Pin Solder	Tin	0.134 in	3.4 mm	10
