857-040 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 80POS 0.156
...
| Part | Contact Finish | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Color | Number of Rows | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Read Out | Termination Rows | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Gender | Pitch [x] | Pitch [x] | Contact Type | Card Type | Material - Insulation | Termination | Flange Feature [diameter] | Flange Feature [diameter] | Flange Feature | Number of Positions/Bay/Row [custom] | Features | Number of Positions/Bay/Row [custom] | Number of Positions/Bay/Row [custom] | Number of Positions/Bay/Row [custom] | Flange Feature | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Gold | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | 2 | 80 | 10 Áin | 0.25 Ám | Through Hole Right Angle | Dual | 1 | 125 °C | -40 °C | Copper Alloy | Female | 0.156 in | 3.96 mm | Semi Bellows | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | Solder | 3.25 mm | 0.128 " | Flush Mount Top Opening Unthreaded | 40 | ||||||
 EDAC Inc. | Tin | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | 2 | 80 | Through Hole | Dual | 1 | 125 °C | -40 °C | Copper Alloy | Female | 0.156 in | 3.96 mm | Semi Bellows | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | Wire Wrap | 2.95 mm | 0.116 in | Floating Bobbin Flush Mount | 40 | ||||||||
 EDAC Inc. | Gold | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | 2 | 40 | 10 Áin | 0.25 Ám | Board Edge Straddle Mount | Dual | 2 | 125 °C | -40 °C | Copper Alloy | Female | 0.156 in | 3.96 mm | Semi Bellows | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | Solder | 4-40 Flush Mount Threaded Insert Top Opening | Card Extender | 20 | 20 | 20 | |||||
 EDAC Inc. | Gold | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | 2 | 40 | 10 Áin | 0.25 Ám | Board Edge Straddle Mount | Dual | 2 | 125 °C | -40 °C | Copper Alloy | Female | 0.156 in | 3.96 mm | Semi Bellows | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | Solder | Card Extender | 20 | 20 | 20 | ||||||
 EDAC Inc. | Gold | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | 2 | 80 | 10 Áin | 0.25 Ám | Through Hole Right Angle | Dual | 1 | 125 °C | -40 °C | Copper Alloy | Female | 0.156 in | 3.96 mm | Semi Bellows | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | Solder | 40 | |||||||||
 EDAC Inc. | Tin | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | 2 | 40 | Through Hole | Dual | 2 | 125 °C | -40 °C | Copper Alloy | Female | 0.156 in | 3.96 mm | Semi Bellows | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | Solder | 4-40 Flush Mount Threaded Insert Top Opening | 20 | 20 | 20 | ||||||||
 EDAC Inc. | Gold | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | 2 | 80 | 10 Áin | 0.25 Ám | Through Hole Right Angle | Dual | 1 | 125 °C | -40 °C | Copper Alloy | Female | 0.156 in | 3.96 mm | Semi Bellows | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | Solder | Side Mount Opening Unthreaded | 40 | 3.25 mm | 0.128 in | ||||||
 EDAC Inc. | Tin | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | 2 | 80 | Through Hole | Dual | 1 | 125 °C | -40 °C | Copper Alloy | Female | 0.156 in | 3.96 mm | Semi Bellows | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | Solder | 2.95 mm | 0.116 in | Floating Bobbin Flush Mount | 40 | ||||||||
 EDAC Inc. | Tin | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | 1 | 40 | Through Hole | Single | 1 | 125 °C | -40 °C | Copper Alloy | Female | 0.156 in | 3.96 mm | Semi Bellows | Non Specified - Single Edge | Polyphenylene Sulfide (PPS) | Solder | 4-40 Flush Mount Threaded Insert Top Opening | 40 | ||||||||||
 EDAC Inc. | Gold | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | 2 | 40 | 10 Áin | 0.25 Ám | Through Hole Right Angle | Single | 2 | 125 °C | -40 °C | Copper Alloy | Female | 0.156 in | 3.96 mm | Semi Bellows | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | Solder | Side Mount Opening Unthreaded | 20 | 20 | 20 | 3.25 mm | 0.128 in |
