HLW28S Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN FFC FPC VERT 28POS 1MM PCB
| Part | Housing Color | Mating Cycles | Housing Material | Termination | Flat Flex Type | Contact Finish | Material Flammability Rating | Height Above Board [z] | Height Above Board [z] | Pitch | Pitch | Voltage Rating | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Connector/Contact Type | Contact Material | Number of Positions | FFC, FCB Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (FCI) | Black | 30 | Polybutylene Terephthalate (PBT) Glass Filled | Kinked Pin | FFC FPC | Tin | UL94 V-0 | 5.9 mm | 0.232 " | 1 mm | 0.039 in | 100 V | Through Hole | -55 C | 85 °C | Contacts Vertical - 1 Sided | Phosphor Bronze | 28 | 0.33 mm |
