CI1503M1 Series
Manufacturer: Cvilux USA
Beta
⌘K
3 POS 1.50MM(.059) WIRE TO BOARD
| Part | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Number of Rows | Shrouding | Termination | Mounting Type | Contact Finish - Post | Contact Material | Insulation Material | Operating Temperature [Max] | Operating Temperature [Min] | Style | Material Flammability Rating | Voltage Rating | Insulation Color | Insulation Height | Insulation Height | Current Rating (Amps) | Connector Type | Contact Length - Mating | Contact Length - Mating | Contact Shape | Fastening Type | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Features | Number of Positions Loaded | Contact Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cvilux USA | 120 Áin | 3.05 Ám | 1 | Shrouded - 4 Wall | Solder | Surface Mount | Tin | Brass | Plastic Halogen Free | 85 °C | -25 °C | Board to Cable/Wire | UL94 V-0 | 50 VAC | Natural | 5.05 mm | 0.199 in | 1 A | Header | 0.093 in | 2.36 mm | Square | Detent Lock | 120 µin | 3.05 µm | Pick and Place Solder Retention | All | Male Pin |
