725 Series
Manufacturer: EDAC Inc.
Beta
⌘K
STANDARD CARD EDGE CONNECTORS PRESS-FIT CARD EDGE CONNECTOR
| Part | Termination Rows | Material - Insulation | Color | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions/Bay/Row | Read Out | Contact Finish | Card Type | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Termination | Number of Rows | Gender | Number of Positions | Pitch | Pitch | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Termination Rows [custom] | Number of Rows [custom] | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Black | -40 C | 105 ░C | 61 | Single | Gold | Non Specified - Single Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Press-Fit | 1 | Female | 61 | 0.1 " | 2.54 mm | Cantilever | 30 Áin | 0.76 Ám | Through Hole | |||
 EDAC Inc. | Black | -40 C | 105 ░C | 19 | Single | Gold | Non Specified - Single Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Press-Fit Wire Wrap | 1 | Female | 19 | 0.1 " | 2.54 mm | Cantilever | 30 Áin | 0.76 Ám | Through Hole | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Black | -40 C | 105 ░C | 61 | Single | Gold | Non Specified - Single Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Press-Fit Wire Wrap | 1 | Female | 61 | 0.1 " | 2.54 mm | Cantilever | 30 Áin | 0.76 Ám | Through Hole | |||
 EDAC Inc. | Polyester Thermoplastic | Black | -40 C | 105 ░C | 45 | Dual | Gold | Non Specified - Dual Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Press-Fit Wire Wrap | Female | 90 | 0.1 " | 2.54 mm | Cantilever | 30 Áin | 0.76 Ám | Through Hole | 2 | 2 | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Black | -40 C | 105 ░C | 63 | Single | Gold | Non Specified - Single Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Press-Fit | 1 | Female | 63 | 0.1 " | 2.54 mm | Cantilever | 30 Áin | 0.76 Ám | Through Hole | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Black | -40 C | 105 ░C | 26 | Single | Gold | Non Specified - Single Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Press-Fit | 1 | Female | 26 | 0.1 " | 2.54 mm | Cantilever | 30 Áin | 0.76 Ám | Through Hole | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Black | -40 C | 105 ░C | 62 | Single | Gold | Non Specified - Single Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Press-Fit | 1 | Female | 62 | 0.1 " | 2.54 mm | Cantilever | 30 Áin | 0.76 Ám | Through Hole | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Black | -40 C | 105 ░C | 47 | Single | Gold | Non Specified - Single Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Press-Fit | 1 | Female | 0.1 " | 2.54 mm | Cantilever | 30 Áin | 0.76 Ám | Through Hole | 47 | |||
 EDAC Inc. | Black | -40 C | 105 ░C | 44 | Single | Gold | Non Specified - Single Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Press-Fit | 1 | Female | 44 | 0.1 " | 2.54 mm | Cantilever | 30 Áin | 0.76 Ám | Through Hole | |||||
 EDAC Inc. | Polyester Thermoplastic | Black | -40 C | 105 ░C | 47 | Dual | Gold | Non Specified - Dual Edge | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Press-Fit Wire Wrap | Female | 94 | 0.1 " | 2.54 mm | Cantilever | 30 Áin | 0.76 Ám | Through Hole | 2 | 2 |
