LEP240F Series
Manufacturer: Cosel USA, Inc.
Beta
⌘K
AC/DC CONVERTER 24V
| Part | Minimum Load Required | Approval Agency | Voltage - Isolation | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Efficiency | Number of Outputs | Current - Output 1 | Mounting Type | Applications | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Output 1 | Type | Voltage - Output 1 [custom] | Features | Power (Watts) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cosel USA, Inc. | CE cURus TUV | 3000 V | 3.74 " | 95 mm | 45 mm | 222 mm | 8.74 in | 1.77 in | 86 % | 1 | 10 A | Chassis Mount | ITE (Commercial) | 70 °C | -10 °C | 24 V | Enclosed | ||||
 Cosel USA, Inc. | CE cURus TUV | 3000 V | 3.74 " | 95 mm | 45 mm | 222 mm | 8.74 in | 1.77 in | 86 % | 1 | 10 A | Chassis Mount | ITE (Commercial) | 70 °C | -10 °C | 24 V | Open Frame | ||||
Cosel USA, Inc. | CE cURus TUV | 3000 V | 3.74 " | 95 mm | 45 mm | 222 mm | 8.74 in | 1.77 in | 87 % | 1 | 6.7 A | Chassis Mount | ITE (Commercial) | 70 °C | -10 °C | Open Frame | 36 V | ||||
Cosel USA, Inc. | CE cURus TUV | 3000 V | 3.74 " | 95 mm | 45 mm | 222 mm | 8.74 in | 1.77 in | 87 % | 1 | 6.7 A | Chassis Mount | ITE (Commercial) | 70 °C | -10 °C | Enclosed | 36 V | ||||
Cosel USA, Inc. | CE cURus TUV | 3000 V | 86 % | 1 | 10 A | Chassis Mount | ITE (Commercial) | 70 °C | -10 °C | 24 V | Enclosed | DC Input Capable Universal Input | 240 Watts | ||||||||
Cosel USA, Inc. | CE cURus TUV | 3000 V | 3.74 " | 95 mm | 45 mm | 222 mm | 8.74 in | 1.77 in | 86 % | 1 | 10 A | Chassis Mount | ITE (Commercial) | 70 °C | -10 °C | 24 V | Enclosed | ||||
Cosel USA, Inc. | CE cURus TUV | 3000 V | 3.74 " | 95 mm | 45 mm | 222 mm | 8.74 in | 1.77 in | 87 % | 1 | 5 A | Chassis Mount | ITE (Commercial) | 70 °C | -10 °C | 48 V | Enclosed | ||||
Cosel USA, Inc. | CE cURus TUV | 3000 V | 3.74 " | 95 mm | 45 mm | 222 mm | 8.74 in | 1.77 in | 87 % | 1 | 6.7 A | Chassis Mount | ITE (Commercial) | 70 °C | -10 °C | Open Frame | 36 V | ||||
Cosel USA, Inc. | CE cURus TUV | 3000 V | 3.74 " | 95 mm | 45 mm | 222 mm | 8.74 in | 1.77 in | 87 % | 1 | 5 A | Chassis Mount | ITE (Commercial) | 70 °C | -10 °C | 48 V | Enclosed | ||||
Cosel USA, Inc. | CE cURus TUV | 3000 V | 3.74 " | 95 mm | 45 mm | 222 mm | 8.74 in | 1.77 in | 86 % | 1 | 10 A | Chassis Mount | ITE (Commercial) | 70 °C | -10 °C | 24 V | Enclosed |
