LCAX Series

Catalog

CONN TERM RECT TONG 650 MCM #3/8

...

Part	Diameter - Ring ID [diameter]	Diameter - Ring ID [diameter]	Contact Material	Contact Finish	Diameter - Barrel ID [diameter]	Diameter - Barrel ID [diameter]	Diameter - Barrel OD [diameter]	Diameter - Barrel OD [diameter]	Stud/Tab Size	Tab Thickness	Tab Thickness	Mounting Type	Wire Gauge	Width - Outer Edges [y]	Width - Outer Edges [y]	Terminal Style	Color	Termination	Terminal Type	Insulation	Diameter - Ring ID	Diameter - Ring ID	Width - Outer Edges	Width - Outer Edges	Width - Outer Edges [x]	Width - Outer Edges [x]	Length - Overall [x]	Length - Overall [x]	Tab Thickness [custom]	Tab Thickness [custom]	Tab Thickness [x]	Tab Thickness [x]	Diameter - Ring ID	Wire Gauge
Panduit Corp LCAX650-38H-6	10.41 mm	0.41 "	Copper	Electro-Tin	1.05 in	26.67 mm	34.29 mm	1.35 in	0.375 Stud	0.3 in	7.62 mm	Free Hanging (In-Line)	650 MCM (kcmil)	1.95 in	49.53 mm	Single Stud Hole	Black	Barrel Crimp	Rectangular Tongue	Non-Insulated
Panduit Corp LCAX2-14H-E			Copper	Electro-Tin	0.36 in	9.14 mm	11.94 mm	0.47 "	0.25 Stud	0.11 in	2.79 mm	Free Hanging (In-Line)	2 AWG			Single Stud Hole	Brown	Barrel Crimp	Rectangular Tongue	Non-Insulated	0.27 in	6.86 mm	0.7 "	17.78 mm
Panduit Corp LCAX1-10-X			Copper	Electro-Tin					10 Stud	0.12 in	3.05 mm	Free Hanging (In-Line)	1 AWG			Single Stud Hole	Green	Barrel Crimp	Rectangular Tongue	Non-Insulated					0.76 "	19.3 mm	38.1 mm	1.5 "
Panduit Corp LCAX500-12-6									0.5 Stud	0.26 in	6.6 mm	Free Hanging (In-Line)	500 MCM			Single Stud Hole	Pink	Barrel Crimp	Rectangular Tongue	Non-Insulated					1.89 in	48.01 mm	92.46 mm	3.64 "
Panduit Corp LCAX650-58H-6	16.76 mm	0.66 in	Copper	Electro-Tin	1.05 in	26.67 mm	34.29 mm	1.35 in	0.625 Stud	0.3 in	7.62 mm	Free Hanging (In-Line)	650 MCM (kcmil)	1.95 in	49.53 mm	Single Stud Hole	Black	Barrel Crimp	Rectangular Tongue	Non-Insulated
Panduit Corp LCAX3/0-38-T	10.41 mm	0.41 "	Copper	Electro-Tin	0.57 "	14.48 mm	18.03 mm	0.71 in	0.375 Stud	0.14 in	3.56 mm	Free Hanging (In-Line)				Single Stud Hole		Barrel Crimp	Rectangular Tongue	Non-Insulated				26.92 mm	1.06 in		55.12 mm	2.17 in
Panduit Corp LCAX6-10F-L	5.08 mm	0.2 in	Copper	Electro-Tin	0.22 in	5.59 mm	7.87 mm	0.31 in	10 Stud			Free Hanging (In-Line) Right Angle	6 AWG	0.45 in	11.43 mm	Single Stud Hole	Blue	Barrel Crimp	Rectangular Tongue	Non-Insulated									0.09 in	2.29 mm
Panduit Corp LCAX2/0-38F-X	10.41 mm	0.41 "	Copper	Electro-Tin	0.51 in	12.95 mm	16.26 mm	0.64 in	0.375 Stud			Free Hanging (In-Line) Right Angle				Single Stud Hole	Black	Barrel Crimp	Rectangular Tongue	Non-Insulated			0.96 in	24.38 mm							3.3 mm	0.13 in
Panduit Corp LCAX650-12H-6			Copper	Electro-Tin	1.05 in	26.67 mm	34.29 mm	1.35 in	0.5 Stud	0.3 in	7.62 mm	Free Hanging (In-Line)	650 MCM (kcmil)	1.95 in	49.53 mm	Single Stud Hole	Black	Barrel Crimp	Rectangular Tongue	Non-Insulated		0.53 in											13.46 mm
Panduit Corp LCAXN750-12-3			Copper	Electro-Tin	1.17 in	29.72 mm	38.1 mm	1.5 in	0.5 Stud	0.33 in	8.38 mm	Free Hanging (In-Line)	750 MCM			Single Stud Hole	Yellow	Barrel Crimp	Rectangular Tongue	Non-Insulated		0.53 in	1.5 in	38.1 mm			100.08 mm	3.94 in					13.46 mm	750 MCM
