392-028 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR ROHS COMPLIANT: YES
| Part | Termination Rows [custom] | Material - Insulation | Contact Finish Thickness | Contact Finish Thickness | Read Out | Contact Type | Number of Positions/Bay/Row | Operating Temperature [Min] | Operating Temperature [Max] | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Number of Positions | Pitch | Pitch | Gender | Contact Material | Contact Finish | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Color | Card Type | Termination | Termination Rows | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | Dual | Cantilever | 14 | -40 C | 105 ░C | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 28 | 0.1 " | 2.54 mm | Female | Copper Alloy | Gold | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Black | Non Specified - Dual Edge | Solder | |||
 EDAC Inc. | Polyester Thermoplastic | 0.25 Ám | 10 Áin | Single | Cantilever | 28 | -40 C | 105 ░C | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 28 | 0.1 " | 2.54 mm | Female | Copper Alloy | Gold | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Non Specified - Single Edge | Wire Wrap | 1 | 1 | |||
 EDAC Inc. | Polyester Thermoplastic | 0.25 Ám | 10 Áin | Single | Cantilever | 28 | -40 C | 105 ░C | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 28 | 0.1 " | 2.54 mm | Female | Copper Alloy | Gold | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Non Specified - Single Edge | Solder Wire Wrap | 1 | 1 | |||
 EDAC Inc. | Polyester Thermoplastic | 0.25 Ám | 10 Áin | Single | Cantilever | 28 | -40 C | 105 ░C | 28 | 0.1 " | 2.54 mm | Female | Copper Alloy | Gold | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Non Specified - Single Edge | Wire Wrap | 1 | 1 | ||||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | Dual | Cantilever | 14 | -40 C | 105 ░C | 28 | 0.1 " | 2.54 mm | Female | Copper Alloy | Gold | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Black | Non Specified - Dual Edge | Solder | ||||||
 EDAC Inc. | Polyester Thermoplastic | 0.25 Ám | 10 Áin | Single | Cantilever | 28 | -40 C | 105 ░C | Flush Mount M3 Threaded Insert Top Opening | 28 | 0.1 " | 2.54 mm | Female | Copper Alloy | Gold | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Non Specified - Single Edge | Wire Wrap | 1 | 1 | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | Dual | Cantilever | 14 | -40 C | 105 ░C | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | 28 | 0.1 " | 2.54 mm | Female | Copper Alloy | Gold | Board Edge Straddle Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Black | Non Specified - Dual Edge | Solder Eyelet(s) | Card Extender | ||
 EDAC Inc. | Polyester Thermoplastic | 0.25 Ám | 10 Áin | Single | Cantilever | 28 | -40 C | 105 ░C | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | 28 | 0.1 " | 2.54 mm | Female | Copper Alloy | Gold | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Non Specified - Single Edge | Solder | 1 | 1 | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | Dual | Cantilever | 14 | -40 C | 105 ░C | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 28 | 0.1 " | 2.54 mm | Female | Copper Alloy | Gold | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Black | Non Specified - Dual Edge | Wire Wrap | |||
 EDAC Inc. | Polyester Thermoplastic | 0.25 Ám | 10 Áin | Single | Cantilever | 28 | -40 C | 105 ░C | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | 28 | 0.1 " | 2.54 mm | Female | Copper Alloy | Gold | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Non Specified - Single Edge | Wire Wrap | 1 | 1 |
