046437 Series
2.00mm, 5.50mm Pitch EXTreme Ten60Power Right-Angle Plug Assembly with Guide Pins, 15 Signal Circuits, 10 Power Circuits
Manufacturer: Molex
Catalog
2.00mm, 5.50mm Pitch EXTreme Ten60Power Right-Angle Plug Assembly with Guide Pins, 15 Signal Circuits, 10 Power Circuits
| Part | Number of Positions Loaded | Number of Positions | Mounting Type | Contact Layout, Typical [custom] | Contact Layout, Typical [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Color | Material Flammability Rating | Contact Finish | Connector Style | Contact Finish Thickness | Contact Finish Thickness | Features | Termination | Connector Type | Current Rating (Amps) | Voltage Rating | Number of Columns | Pitch [x] | Pitch [x] | Number of Rows | Contact Layout, Typical |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Molex | All | 30 | Through Hole Right Angle | 6 | 24 | -40 °C | 105 ░C | Black | UL94 V-0 | Gold | EXTreme Ten60Power | 0.76 Ám | 30 Áin | Board Guide Guide Pin | Solder | Plug Male Pins and Blades | |||||||
Molex | |||||||||||||||||||||||
Molex | All | 31 | Through Hole Right Angle | 7 | 24 | -40 °C | 105 ░C | Black | UL94 V-0 | Gold | EXTreme Ten60Power | 0.76 Ám | 30 Áin | Board Guide Guide Pin | Solder | Plug Male Pins and Blades | |||||||
Molex | All | 28 | Through Hole Right Angle | 4 | 24 | -40 °C | 105 ░C | Black | UL94 V-0 | Gold | EXTreme Ten60Power | 0.76 Ám | 30 Áin | Board Guide Guide Pin | Solder | Plug Male Pins and Blades | |||||||
 Molex | All | 35 | Through Hole Right Angle | 10 | 30 | -40 °C | 105 ░C | Black | UL94 V-0 | Gold | EXTreme Ten60Power | 0.76 Ám | 30 Áin | Board Guide Guide Pin | Press-Fit | Plug Male Pins and Blades | 60 A | 250 VDC 600 VAC | |||||
 Molex | All | 19 | Through Hole Right Angle | 4 | 15 | -40 °C | 105 ░C | Black | UL94 V-0 | Gold | EXTreme Ten60Power | 0.76 Ám | 30 Áin | Board Guide Guide Pin | Press-Fit | Plug Male Pins and Blades | 60 A | 250 VDC 600 VAC | |||||
 Molex | All | Through Hole Right Angle | 2 | 15 | -40 °C | 105 ░C | Black | UL94 V-0 | Gold | EXTreme Ten60Power | 0.76 Ám | 30 Áin | Board Guide Guide Pin | Press-Fit | Plug Male Pins and Blades | 60 A | 250 VDC 600 VAC | ||||||
 Molex | All | 10 | Through Hole Right Angle | -40 °C | 105 ░C | Black | UL94 V-0 | Gold | EXTreme Ten60Power | 0.76 Ám | 30 Áin | Board Guide Guide Pin | Press-Fit | Male Pins Plug | 4.5 A | 120 VDC | 2 | 0.079 in | 2 mm | 5 | |||
 Molex | All | 4 | Through Hole Right Angle | -40 °C | 105 ░C | Black | UL94 V-0 | Gold | EXTreme Ten60Power | 0.76 Ám | 30 Áin | Board Guide Guide Pin | Press-Fit | Plug Male Blades | 60 A | 250 VDC 600 VAC | 0.217 in | 5.5 mm | 1 | 4 Power | |||
 Molex | All | 18 | Through Hole Right Angle | 6 | 15 | -40 °C | 105 ░C | Black | UL94 V-0 | Gold | EXTreme Ten60Power | 0.76 Ám | 30 Áin | Board Guide Guide Pin | Press-Fit | Plug Male Pins and Blades | 60 A | 250 VDC 600 VAC |
