OSTYD03 Series
Manufacturer: On Shore Technology Inc.
Beta
⌘K
TERM BLK 3POS SIDE ENTRY 5MM PCB
| Part | Clamp Material - Plating | Screw Thread | Housing Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material - Plating | Torque - Screw | Torque - Screw | Screw Material - Plating | Features | Current | Positions Per Level | Pitch | Pitch | Voltage | Mating Orientation | Wire Termination | Number of Levels | Mounting Type | Color | Wire Gauge [Max] | Wire Gauge [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 On Shore Technology Inc. | Brass | M2.5 | Thermoplastic | -30 ░C | 105 ░C | Brass | 3.5 Lb-In | 0.4 Nm | Steel - Zinc Plated | Interlocking (Side) | 10 A | 3 | 0.197 in | 5 mm | 300 VDC | Horizontal with Board | Screw - Rising Cage Clamp | 1 | Through Hole | Green | 24 AWG | 12 AWG |
