91A1D Series
Manufacturer: Bourns Inc.
Beta
⌘K
POT 10K OHM 1W PLASTIC LINEAR
| Part | Size - Body [x] | Size - Body [x] | Size - Body [y] | Size - Body [y] | Actuator Type | Taper | Tolerance | Power (Watts) | Termination Style | Bushing Thread | Temperature Coefficient | Actuator Diameter [diameter] | Actuator Diameter [diameter] | Rotation | Built in Switch | Number of Gangs | Actuator Length [x] | Actuator Length [x] | Mounting Type | Resistive Material | Number of Turns | Resistance (Ohms) | Adjustment Type | Resistance (Ohms) | Resistance (Ohms) [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 17.45 mm | 0.687 " | 0.625 " | 15.88 mm | Slotted | Linear | 20 % | 1 W | PC Pins | 3/8-32 | 1000 ppm/°C | 6.35 mm | 0.25 in | 300 ░ | None | 1 | 19.05 mm | 0.75 in | Panel Mount | Conductive Plastic | 1 | 10k | Side Adjustment | ||
 Bourns Inc. | 17.45 mm | 0.687 " | 0.625 " | 15.88 mm | Flatted | Linear | 10 % | 2 W | PC Pins | 3/8-32 | 150 ppm/°C | 6.35 mm | 0.25 in | 300 ░ | None | 1 | 19.05 mm | 0.75 in | Panel Mount | Cermet | 1 | Side Adjustment | 5 kOhms | ||
Bourns Inc. | 17.45 mm | 0.687 " | 0.625 " | 15.88 mm | Slotted | Linear | 20 % | 1 W | PC Pins | 3/8-32 | 1000 ppm/°C | 6.35 mm | 0.25 in | 300 ░ | None | 1 | 19.05 mm | 0.75 in | Panel Mount | Conductive Plastic | 1 | Side Adjustment | 50 kOhms | ||
 Bourns Inc. | 17.45 mm | 0.687 " | 0.625 " | 15.88 mm | Slotted | Linear | 20 % | 1 W | PC Pins | 3/8-32 | 1000 ppm/°C | 6.35 mm | 0.25 in | 300 ░ | None | 1 | 22.23 mm | 0.875 in | Panel Mount | Conductive Plastic | 1 | 100k | Side Adjustment | ||
 Bourns Inc. | 17.45 mm | 0.687 " | 0.625 " | 15.88 mm | Slotted | Linear | 10 % | 2 W | PC Pins | 3/8-32 | 150 ppm/°C | 6.35 mm | 0.25 in | 300 ░ | None | 1 | 22.23 mm | 0.875 in | Panel Mount | Cermet | 1 | 10k | Side Adjustment |
