794622 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

CONN HEADER SMD R/A 8POS 3MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Applications	Insulation Material	Insulation Color	Style	Material Flammability Rating	Number of Positions	Insulation Height	Insulation Height	Contact Finish - Post	Shrouding	Number of Rows [custom]	Row Spacing - Mating	Row Spacing - Mating	Contact Type	Fastening Type	Contact Shape	Number of Positions Loaded	Contact Material	Pitch - Mating	Pitch - Mating	Termination	Voltage Rating	Current Rating (Amps)	Mounting Type	Features	Contact Finish - Mating	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Connector Type
TE Connectivity AMP Connectors 3-794622-8	2.54 µm	100 µin	General Purpose	Nylon Polyamide (PA)	Black	Board to Cable/Wire	UL94 V-0	8	0.29 in	7.37 mm	Tin	Shrouded - 4 Wall	2	0.118 in	3 mm	Male Pin	Locking Ramp	Square	All	Brass	3 mm	0.118 in	Solder	250 V	Varies by Wire Gauge	Right Angle Surface Mount	Board Lock	Gold	-40 C	105 ░C	0.38 µm	15 µin	Header
TE Connectivity AMP Connectors 1-794622-0	2.54 µm	100 µin	General Purpose	Nylon Polyamide (PA)	Black	Board to Cable/Wire	UL94 V-0	10	0.29 in	7.37 mm	Tin-Lead	Shrouded - 4 Wall	2	0.118 in	3 mm	Male Pin	Locking Ramp	Square	All	Brass	3 mm	0.118 in	Solder	250 V	Varies by Wire Gauge	Right Angle Surface Mount	Board Lock	Gold	-40 C	105 ░C	0.38 µm	15 µin	Header
TE Connectivity AMP Connectors 3-794622-4	2.54 µm	100 µin	General Purpose	Nylon Polyamide (PA)	Black	Board to Cable/Wire	UL94 V-0	4	0.29 in	7.37 mm	Tin	Shrouded - 4 Wall	2	0.118 in	3 mm	Male Pin	Locking Ramp	Square	All	Brass	3 mm	0.118 in	Solder	250 V	Varies by Wire Gauge	Right Angle Surface Mount	Board Lock	Gold	-40 C	105 ░C	0.38 µm	15 µin	Header
