RU4S-M Series
Manufacturer: IDEC
Beta
⌘K
RELAY PLUG-IN 4PDT 6A 24VDC ROHS COMPLIANT: YES
| Part | Coil Resistance | Contact Rating (Current) | Contact Material | Contact Form | Termination Style | Coil Voltage | Approval Agency | Relay Type | Coil Current | Mounting Type | Coil Type | Operate Time | Must Release Voltage | Release Time | Must Operate Voltage | Operating Temperature [Max] | Operating Temperature [Min] | Switching Voltage [Max] | Load - Max Switching | Termination Style | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 IDEC | 605 Ohms | 6 A | Gold (Au) Silver (Ag) | 4PDT (4 Form C) | Plug In | 24 VDC | CE CSA cURus TUV | General Purpose | 44.7 mA | Socketable | Non Latching | 20 ms | 2.4 VDC | 20 ms | 19.2 VDC | 60 °C | -55 C | 30 VDC 250 VAC | 300 W 2500 VA | ||
 IDEC | 18.23 kOhms | 6 A | Gold (Au) Silver (Ag) | 4PDT (4 Form C) | Plug In | 220 VAC/DC | CE CSA cURus TUV | General Purpose | 3.6 mA | Socketable | Non Latching | 20 ms | 66 VAC | 20 ms | 176 VAC | 60 °C | -55 C | 30 VDC 250 VAC | 300 W 2500 VA | 14 Pin | Lighted Indicator Mechanical Indicator |
IDEC | 2560 Ohms | 6 A | Gold (Au) Silver (Ag) | 4PDT (4 Form C) | Plug In | 48 VDC | CE CSA cURus TUV | General Purpose | 18 mA | Socketable | Non Latching | 20 ms | 4.8 VDC | 20 ms | 38.4 VDC | 60 °C | -55 C | 30 VDC 250 VAC | 300 W 2500 VA | 14 Pin | Lighted Indicator Mechanical Indicator |
IDEC | 12.1 kOhms | 6 A | Gold (Au) Silver (Ag) | 4PDT (4 Form C) | Plug In | 110 VDC | CE CSA cURus TUV | General Purpose | 8.9 mA | Socketable | Non Latching | 20 ms | 11 VDC | 20 ms | 88 VDC | 60 °C | -55 C | 30 VDC 250 VAC | 300 W 2500 VA | 14 Pin | Diode Lighted Indicator Mechanical Indicator |
IDEC | 605 Ohms | 6 A | Gold (Au) Silver (Ag) | 4PDT (4 Form C) | Plug In | 24 VDC | CE CSA cURus TUV | General Purpose | 44.7 mA | Socketable | Non Latching | 20 ms | 2.4 VDC | 20 ms | 19.2 VDC | 60 °C | -55 C | 30 VDC 250 VAC | 300 W 2500 VA | 14 Pin | Diode Lighted Indicator Mechanical Indicator Reverse Coil Polarity |
IDEC | 4.55 kOhms | 6 A | Gold (Au) Silver (Ag) | 4PDT (4 Form C) | Plug In | 110 VAC/DC | CE CSA cURus TUV | General Purpose | 7.1 mA | Socketable | Non Latching | 20 ms | 33 VAC | 20 ms | 88 VAC/DC | 60 °C | -55 C | 30 VDC 250 VAC | 300 W 2500 VA | 14 Pin | Lighted Indicator Mechanical Indicator RC Circuit |
IDEC | 160 Ohms | 6 A | Gold (Au) Silver (Ag) | 4PDT (4 Form C) | Plug In | 12 VDC | CE CSA cURus TUV | General Purpose | 80 mA | Socketable | Non Latching | 20 ms | 1.2 VDC | 20 ms | 9.6 VDC | 60 °C | -55 C | 30 VDC 250 VAC | 300 W 2500 VA | 14 Pin | Diode Lighted Indicator Mechanical Indicator |
