PESE1 Series

Manufacturer: CUI Inc.

Catalog

ISOLATED DC/DC CONVERTERS - SMD 9/-9 VDC, 0.056/-0.056 A, 1 W, 4.5 - 5.5

Part	Voltage - Output 2	Package / Case	Type	Voltage - Input (Max) [Max]	Mounting Type	Voltage - Input (Min) [Min]	Standard Number	Efficiency	Approval Agency	Features	Applications	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Number of Outputs	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Output 1	Current - Output (Max) [Max]	Voltage - Isolation	Current - Output (Max) [Max]	Current - Output (Max)	Current - Output (Max)
CUI Inc. PESE1-S5-D9-M	-9 V	10-SMD Module 6 Leads	Isolated Module	5.5 V	Surface Mount	4.5 V	55024 55032 Class A 62368-1	83 %	CB Scheme EN IEC	SCP	ITE (Commercial)	0.33 "	7.3 mm	0.29 in	8.5 mm	15.2 mm	0.6 "	2	105 C	-40 °C	9 V	56 mA	3000 V
CUI Inc. PESE1-S5-D15-M	-15 V	10-SMD Module 6 Leads	Isolated Module	5.5 V	Surface Mount	4.5 V	55024 55032 Class A 62368-1	83 %	CB Scheme EN IEC	SCP	ITE (Commercial)	0.33 "	7.3 mm	0.29 in	8.5 mm	15.2 mm	0.6 "	2	105 C	-40 °C	15 V	34 mA	3000 V	34 mA
CUI Inc. PESE1-S5-D15-M-TR	-15 V	10-SMD Module 6 Leads	Isolated Module	5.5 V	Surface Mount	4.5 V	55024 55032 Class A 62368-1	83 %	CB Scheme EN IEC	SCP	ITE (Commercial)	0.33 "	7.3 mm	0.29 in	8.5 mm	15.2 mm	0.6 "	2	105 C	-40 °C	15 V	34 mA	3000 V	34 mA
CUI Inc. PESE1-S5-S15-M-TR		8-SMD Module 5 Leads	Isolated Module	5.5 V	Surface Mount	4.5 V	55024 55032 Class A 62368-1	83 %	CB Scheme EN IEC UL	SCP	ITE (Commercial)	0.33 "	7.3 mm	0.29 in	8.5 mm	13.2 mm	0.52 in	1	105 C	-40 °C	15 V	67 mA	3000 V
CUI Inc. PESE1-S5-S5-M-TR		8-SMD Module 5 Leads	Isolated Module	5.5 V	Surface Mount	4.5 V	55024 55032 Class A 62368-1		CB Scheme EN IEC UL	SCP	ITE (Commercial)	0.33 "	7.3 mm	0.29 in	8.5 mm	13.2 mm	0.52 in	1	105 C	-40 °C	5 V	200 mA	3000 V
CUI Inc. PESE1-S5-S3-M-TR		8-SMD Module 5 Leads	Isolated Module	5.5 V	Surface Mount	4.5 V	55024 55032 Class A 62368-1	74 %	CB Scheme EN IEC UL	SCP	ITE (Commercial)	0.33 "	7.3 mm	0.29 in	8.5 mm	13.2 mm	0.52 in	1	105 C	-40 °C	3.3 V	303 mA	3000 V
CUI Inc. PESE1-S5-S24-M-TR		8-SMD Module 5 Leads	Isolated Module	5.5 V	Surface Mount	4.5 V	55024 55032 Class A 62368-1	85 %	CB Scheme EN IEC UL	SCP	ITE (Commercial)	0.33 "	7.3 mm	0.29 in	8.5 mm	13.2 mm	0.52 in	1	105 C	-40 °C	24 V	42 mA	3000 V
CUI Inc. PESE1-S5-S15-M		8-SMD Module 5 Leads	Isolated Module	5.5 V	Surface Mount	4.5 V	55024 55032 Class A 62368-1	83 %	CB Scheme EN IEC UL	SCP	ITE (Commercial)	0.33 "	7.3 mm	0.29 in	8.5 mm	13.2 mm	0.52 in	1	105 C	-40 °C	15 V	67 mA	3000 V
CUI Inc. PESE1-S5-D5-M-TR	-5 V	10-SMD Module 6 Leads	Isolated Module	5.5 V	Surface Mount	4.5 V	55024 55032 Class A 62368-1		CB Scheme EN IEC	SCP	ITE (Commercial)	0.33 "	7.3 mm	0.29 in	8.5 mm	15.2 mm	0.6 "	2	105 C	-40 °C	5 V		3000 V		100 mA	100 mA
CUI Inc. PESE1-S5-D9-M-TR	-9 V	10-SMD Module 6 Leads	Isolated Module	5.5 V	Surface Mount	4.5 V	55024 55032 Class A 62368-1	83 %	CB Scheme EN IEC	SCP	ITE (Commercial)	0.33 "	7.3 mm	0.29 in	8.5 mm	15.2 mm	0.6 "	2	105 C	-40 °C	9 V	56 mA	3000 V
