337-021 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 21POS 0.156
| Part | Material - Insulation | Termination Rows | Flange Feature | Number of Positions | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row [custom] | Mounting Type | Color | Contact Material | Number of Rows | Gender | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Card Type | Pitch | Pitch | Operating Temperature [Min] | Operating Temperature [Max] | Read Out | Termination | Features | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | 4-40 Threaded Insert Top Mount Opening | 21 | Gold | 0.25 Ám | 10 Áin | 21 | Through Hole | Green | Copper Alloy | 1 | Female | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 3.96 mm | 0.156 in | -40 C | 105 ░C | Single | Wire Wrap | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Flush Mount Side Opening Unthreaded | 21 | Gold | 0.25 Ám | 10 Áin | 21 | Through Hole | Green | Copper Alloy | 1 | Female | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 3.96 mm | 0.156 in | -40 C | 105 ░C | Single | Wire Wrap | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | 21 | Gold | 0.25 Ám | 10 Áin | 21 | Through Hole | Green | Copper Alloy | 1 | Female | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 3.96 mm | 0.156 in | -40 C | 105 ░C | Single | Solder Eyelet(s) | 0.128 " | 3.25 mm | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Flush Mount Top Opening Unthreaded | 21 | Gold | 0.25 Ám | 10 Áin | 21 | Through Hole | Green | Copper Alloy | 1 | Female | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 3.96 mm | 0.156 in | -40 C | 105 ░C | Single | Solder | 0.156 " | 3.96 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Floating Bobbin Flush Mount | 21 | Gold | 0.25 Ám | 10 Áin | 21 | Through Hole | Green | Copper Alloy | 1 | Female | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 3.96 mm | 0.156 in | -40 C | 105 ░C | Single | Wire Wrap | 0.116 " | 2.95 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | 21 | Gold | 0.25 Ám | 10 Áin | 21 | Through Hole | Green | Copper Alloy | 1 | Female | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 3.96 mm | 0.156 in | -40 C | 105 ░C | Single | Solder | 0.156 " | 3.96 mm | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 4-40 Flush Mount Threaded Insert Top Opening | 21 | Gold | 0.25 Ám | 10 Áin | 21 | Right Angle Through Hole | Green | Copper Alloy | 1 | Female | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 3.96 mm | 0.156 in | -40 C | 105 ░C | Single | Wire Wrap | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 4-40 Flush Mount Threaded Insert Top Opening | 21 | Gold | 0.25 Ám | 10 Áin | 21 | Through Hole | Green | Copper Alloy | 1 | Female | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 3.96 mm | 0.156 in | -40 C | 105 ░C | Single | Solder | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Side Mount Opening Unthreaded | 21 | Gold | 0.25 Ám | 10 Áin | 21 | Right Angle Through Hole | Green | Copper Alloy | 1 | Female | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 3.96 mm | 0.156 in | -40 C | 105 ░C | Single | Wire Wrap | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | 4-40 Flush Mount Threaded Insert Top Opening | 21 | Gold | 0.25 Ám | 10 Áin | 21 | Through Hole | Green | Copper Alloy | 1 | Female | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 3.96 mm | 0.156 in | -40 C | 105 ░C | Single | Solder | Card Guides |
