EAST16086 Series

Manufacturer: Everlight Electronics Co Ltd

Catalog

LED RED CLEAR 2SMD

Part	Wavelength - Dominant	Voltage - Forward (Vf) (Typ)	Viewing Angle	Wavelength - Peak	Size / Dimension [x]	Size / Dimension [y]	Millicandela Rating	Lens Color	Configuration	Lens Transparency	Mounting Type	Lens Size [y]	Lens Size [x]	Height (Max) [z]	Supplier Device Package	Package / Case	Package / Case	Lens Style	Current - Test	Color	Wavelength - Dominant [custom]
Everlight Electronics Co Ltd EAST16086RA7	632 nm	2 V	120 °	639 nm	1.6 mm	0.8 mm	126 mcd	Colorless	Standard	Clear	Surface Mount	0.8 mm	1.2 mm	0.7 mm	2-SMD	1608 Metric	0603	Rectangle with Flat Top	20 mA	Red
Everlight Electronics Co Ltd EAST16086GA3	572 nm	2.05 V	120 °	575 nm	1.6 mm	0.8 mm	32 mcd	Colorless	Standard	Clear	Surface Mount	0.8 mm	1.2 mm	0.7 mm	2-SMD	1608 Metric	0603	Rectangle with Flat Top	20 mA	Yellow-Green
Everlight Electronics Co Ltd EAST16086GA4	572 nm	2 V	120 °	575 nm	1.6 mm	0.8 mm	63 mcd	Colorless	Standard	Clear	Surface Mount	0.8 mm	1.2 mm	0.7 mm	2-SMD	1608 Metric	0603	Rectangle with Flat Top	20 mA	Yellow-Green
Everlight Electronics Co Ltd EAST16086BA2	466 nm	3.3 V	120 °	468 nm	1.6 mm	0.8 mm	54 mcd	Colorless	Standard	Clear	Surface Mount	0.8 mm	1.2 mm	0.7 mm	2-SMD	1608 Metric	0603	Rectangle with Flat Top	20 mA	Blue
Everlight Electronics Co Ltd EAST16086GA6		3 V	120 °	518 nm	1.6 mm	0.8 mm	79 mcd	Colorless	Standard	Clear	Surface Mount	0.8 mm	1.2 mm	0.7 mm	2-SMD	1608 Metric	0603	Rectangle with Flat Top	5 mA	Green	528 nm
Everlight Electronics Co Ltd EAST16086BA1	471 nm	3.3 V	120 °	468 nm	1.6 mm	0.8 mm	50 mcd	Colorless	Standard	Clear	Surface Mount	0.8 mm	1.2 mm	0.7 mm	2-SMD	1608 Metric	0603	Rectangle with Flat Top	20 mA	Blue
Everlight Electronics Co Ltd EAST16086BA3	471 nm	3.3 V	120 °	468 nm	1.6 mm	0.8 mm	79 mcd	Clear Colorless	Standard	Clear	Surface Mount	0.8 mm	1.2 mm	0.7 mm	2-SMD		2-SMD No Lead	Rectangle with Flat Top	20 mA	Blue
Everlight Electronics Co Ltd EAST16086AA0	607 nm	2.05 V	120 °	611 nm	1.6 mm	0.8 mm	50 mcd	Colorless	Standard	Clear	Surface Mount	0.8 mm	1.2 mm	0.7 mm	2-SMD	1608 Metric	0603	Rectangle with Flat Top	20 mA
Everlight Electronics Co Ltd EAST16086GA5	572 nm	2.05 V	130 °	575 nm	1.6 mm	0.8 mm	43 mcd	White	Standard	Diffused	Surface Mount	0.8 mm	1.2 mm	0.7 mm	2-SMD	1608 Metric	0603	Rectangle with Flat Top	20 mA	Yellow-Green
Everlight Electronics Co Ltd EAST16086YA5	590 nm	2 V	120 °	591 nm	1.6 mm	0.8 mm	54 mcd	Colorless	Standard	Clear	Surface Mount	0.8 mm	1.2 mm	0.7 mm	2-SMD	1608 Metric	0603	Rectangle with Flat Top	10 mA	Yellow
