892-026 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 26POS 0.100
| Part | Termination Rows | Material - Insulation | Color | Contact Type | Termination | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Contact Finish | Contact Material | Pitch | Pitch | Number of Positions | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Mounting Type | Read Out | Card Type | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Termination Rows [custom] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | Cantilever | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 26 | Gold | Copper Alloy | 0.1 " | 2.54 mm | 26 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Right Angle Through Hole | Single | Non Specified - Single Edge | Female | 125 °C | -40 C | 1 | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Black | Cantilever | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 13 | Gold | Copper Alloy | 0.1 " | 2.54 mm | 26 | Through Hole | Dual | Non Specified - Dual Edge | Female | 125 °C | -40 C | 0.25 Ám | 10 Áin | 2 | 2 | ||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | Cantilever | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 26 | Gold | Copper Alloy | 0.1 " | 2.54 mm | 26 | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Through Hole | Single | Non Specified - Single Edge | Female | 125 °C | -40 C | 1 | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | Cantilever | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 26 | Gold | Copper Alloy | 0.1 " | 2.54 mm | 26 | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | Through Hole | Single | Non Specified - Single Edge | Female | 125 °C | -40 C | 1 | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | Cantilever | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 26 | Gold | Copper Alloy | 0.1 " | 2.54 mm | 26 | Through Hole | Single | Non Specified - Single Edge | Female | 125 °C | -40 C | 1 | 0.25 Ám | 10 Áin | ||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | Cantilever | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 26 | Gold | Copper Alloy | 0.1 " | 2.54 mm | 26 | Right Angle Through Hole | Single | Non Specified - Single Edge | Female | 125 °C | -40 C | 1 | 0.25 Ám | 10 Áin | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Black | Cantilever | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 13 | Gold | Copper Alloy | 0.1 " | 2.54 mm | 26 | Flush Mount M3 Threaded Insert Top Opening | Right Angle Through Hole | Dual | Non Specified - Dual Edge | Female | 125 °C | -40 C | 0.25 Ám | 10 Áin | 2 | 2 | |||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | Cantilever | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 26 | Gold | Copper Alloy | 0.1 " | 2.54 mm | 26 | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Through Hole | Single | Non Specified - Single Edge | Female | 125 °C | -40 C | 1 | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Black | Cantilever | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 13 | Gold | Copper Alloy | 0.1 " | 2.54 mm | 26 | 4-40 Flush Mount Threaded Insert Top Opening | Board Edge Straddle Mount | Dual | Non Specified - Dual Edge | Female | 125 °C | -40 C | 0.25 Ám | 10 Áin | 2 | 2 | Card Extender | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Black | Cantilever | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 13 | Gold | Copper Alloy | 0.1 " | 2.54 mm | 26 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Through Hole | Dual | Non Specified - Dual Edge | Female | 125 °C | -40 C | 0.25 Ám | 10 Áin | 2 | 2 |
