802-V3 Series

Manufacturer: Preci-Dip

Catalog

Catalog

CONN HEADER SMD 46POS 2.54MM

...

Part	Number of Positions	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Shape	Contact Material	Pitch - Mating	Pitch - Mating	Number of Rows [custom]	Insulation Material	Connector Type	Termination	Number of Positions Loaded	Fastening Type	Contact Finish - Post	Voltage Rating	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Contact Finish - Mating	Contact Length - Mating	Contact Length - Mating	Insulation Color	Insulation Height	Insulation Height	Contact Type	Contact Finish Thickness - Mating [custom]	Contact Finish Thickness - Mating [custom]	Material Flammability Rating	Current Rating (Amps)	Shrouding	Features	Contact Length - Post	Contact Length - Post	Overall Contact Length [x]	Overall Contact Length [x]	Insulation Height [z]	Overall Contact Length	Overall Contact Length	Insulation Height [z]	Contact Length - Post [x]	Contact Length - Post [x]
Preci-Dip 802-V3-046-32-002101	46	0.1 in	2.54 mm	Circular	Brass	0.1 "	2.54 mm	2	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	Solder	All	Push-Pull	Tin	150 VDC	-55 C	125 °C	Surface Mount	Gold	0.141 in	3.6 mm	Black	0.272 in	6.91 mm	Male Pin	29.5 µin	0.75 µm	UL94 V-0	3 A	Unshrouded
Preci-Dip 802-V3-018-30-001101	18	0.1 in	2.54 mm	Circular	Brass	0.1 "	2.54 mm	2	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	Solder	All	Push-Pull	Tin	150 VDC	-55 C	125 °C	Surface Mount	Gold	0.191 in	4.85 mm	Black			Male Pin	29.5 µin	0.75 µm	UL94 V-0	3 A	Unshrouded
Preci-Dip 802-V3-010-32-002191	10	0.1 in	2.54 mm	Circular	Brass	0.1 "	2.54 mm	2	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	Solder	All	Push-Pull	Tin	150 VDC	-55 C	125 °C	Surface Mount	Gold	0.141 in	3.6 mm	Black	0.272 in	6.91 mm	Male Pin	29.5 µin	0.75 µm	UL94 V-0	3 A	Unshrouded	Pick and Place
Preci-Dip 802-V3-010-10-193101	10	0.1 in	2.54 mm	Circular	Brass	0.1 "	2.54 mm	2	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	Solder	All	Push-Pull	Tin	150 VDC	-55 C	125 °C	Through Hole	Gold	0.118 in	3 mm	Black		21.21 mm	Male Pin	29.5 µin	0.75 µm	UL94 V-0	3 A	Unshrouded		3.56 mm	0.14 in	1.093 in	27.75 mm	0.835 in
Preci-Dip 802-V3-040-12-002101	40	0.1 in	2.54 mm	Circular	Brass	0.1 "	2.54 mm	2	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	Solder	All	Push-Pull	Tin	150 VDC	-55 C	125 °C	Through Hole	Gold	0.141 in	3.6 mm	Black	0.272 in	6.91 mm	Male Pin	29.5 µin	0.75 µm	UL94 V-0	3 A	Unshrouded		3 mm	0.118 in				9.8 mm	0.386 in
Preci-Dip 802-V3-060-12-002101	60	0.1 in	2.54 mm	Circular	Brass	0.1 "	2.54 mm	2	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	Solder	All	Push-Pull	Tin	150 VDC	-55 C	125 °C	Through Hole	Gold	0.141 in	3.6 mm	Black	0.272 in	6.91 mm	Male Pin	29.5 µin	0.75 µm	UL94 V-0	3 A	Unshrouded		3 mm	0.118 in				9.8 mm	0.386 in
Preci-Dip 802-V3-006-30-001101	6	0.1 in	2.54 mm	Circular	Brass	0.1 "	2.54 mm	2	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	Solder	All	Push-Pull	Tin	150 VDC	-55 C	125 °C	Surface Mount	Gold	0.191 in	4.85 mm	Black			Male Pin	29.5 µin	0.75 µm	UL94 V-0	3 A	Unshrouded
Preci-Dip 802-V3-032-20-001101		0.1 in	2.54 mm	Circular	Brass	0.1 "	2.54 mm	2	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	Solder	All	Push-Pull	Tin	150 VDC	-55 C	125 °C	Right Angle Through Hole	Gold	0.195 in	4.95 mm	Black			Male Pin	29.5 µin	0.75 µm	UL94 V-0	3 A	Unshrouded						0.2 in			5.08 mm	0.126 "	3.2 mm
Preci-Dip 802-V3-016-32-002101	16	0.1 in	2.54 mm	Circular	Brass	0.1 "	2.54 mm	2	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	Solder	All	Push-Pull	Tin	150 VDC	-55 C	125 °C	Surface Mount	Gold	0.141 in	3.6 mm	Black	0.272 in	6.91 mm	Male Pin	29.5 µin	0.75 µm	UL94 V-0	3 A	Unshrouded
Preci-Dip 802-V3-030-20-001101	30	0.1 in	2.54 mm	Circular	Brass	0.1 "	2.54 mm	2	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	Solder	All	Push-Pull	Tin	150 VDC	-55 C	125 °C	Right Angle Through Hole	Gold	0.195 in	4.95 mm	Black			Male Pin	29.5 µin	0.75 µm	UL94 V-0	3 A	Unshrouded						0.2 in			5.08 mm	0.126 "	3.2 mm
