BC638%20(LEGACY%20FAIRCHILD) Series

Transistor Silicon Plastic PNP

Catalog

Transistor Silicon Plastic PNP

Part	Mounting Type	DC Current Gain (hFE) (Min) @ Ic, Vce [Min]	Operating Temperature	Vce Saturation (Max) @ Ib, Ic	Supplier Device Package	Current - Collector Cutoff (Max) [Max]	Transistor Type	Package / Case	Frequency - Transition	Voltage - Collector Emitter Breakdown (Max)	Current - Collector (Ic) (Max) [Max]	Power - Max [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Supplier Device Package
ON Semiconductor BC638TA	Through Hole	40	150 °C	500 mV	TO-92-3	100 nA	PNP	TO-226-3 TO-92-3	100 MHz	60 V	1 A	1 W
ON Semiconductor BC638	Through Hole	40		500 mV	TO-92	100 nA	PNP	TO-226-3 TO-92-3 Long Body	150 MHz	60 V	500 mA	625 mW	-55 °C	150 °C	TO-226
ON Semiconductor BC638TF	Through Hole	40	150 °C	500 mV	TO-92-3	100 nA	PNP	TO-226-3 TO-92-3	100 MHz	60 V	1 A	1 W
ON Semiconductor BC638ZL1	Through Hole	40		500 mV	TO-92	100 nA	PNP	Formed Leads TO-226-3 TO-92-3 Long Body	150 MHz	60 V	500 mA	625 mW	-55 °C	150 °C	TO-226
ON Semiconductor BC638BU	Through Hole	40	150 °C	500 mV	TO-92-3	100 nA	PNP	TO-226-3 TO-92-3	100 MHz	60 V	1 A	1 W
ON Semiconductor BC638ZL1G	Through Hole	40		500 mV	TO-92	100 nA	PNP	Formed Leads TO-226-3 TO-92-3 Long Body	150 MHz	60 V	500 mA	625 mW	-55 °C	150 °C	TO-226

Catalog

Transistor Silicon Plastic PNP

Key Features

• Pb-Free Packages are Available

Description

The PNP Bipolar Transistor is designed for use in linear and switching applications. The device is housed in the TO-92 package, which is designed for medium power applications.Replacement Active Part Number:BC638
