E2A-S08 Series
Manufacturer: Omron Automation and Safety
Beta
⌘K
SENSOR PROX INDUCTIVE 4MM CYLIND
| Part | Sensor Type | Output Type | Ingress Protection | Indicator | Voltage - Supply [Max] | Voltage - Supply [Min] | Shielding | Response Frequency | Material - Body | Operating Temperature [Max] | Operating Temperature [Min] | Sensing Distance | Sensing Distance | Termination Style | Package / Case | Output Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Automation and Safety | Inductive | 3-Wire NPN-NO | IP67 IP69K | LED | 32 VDC | 10 VDC | Unshielded | 1 kHz | Stainless Steel | 70 °C | -40 C | 4 mm | 0.157 in | Cable Leads | Cylinder Threaded - M8 | |
 Omron Automation and Safety | Inductive | 3-Wire NPN-NO | IP67 IP69K | LED | 32 VDC | 10 VDC | Unshielded | 1 kHz | Stainless Steel | 70 °C | -40 C | 4 mm | 0.157 in | Connector | Cylinder Threaded - M8 | |
 Omron Automation and Safety | Inductive | PNP-NO | IP67 IP69K | LED | 32 VDC | 10 VDC | Shielded | 1.5 kHz | Stainless Steel | 70 °C | -40 C | 2 mm | 0.079 in | Connector | Cylinder Threaded - M8 | 3 |
 Omron Automation and Safety | Inductive | 3-Wire NPN-NC | IP67 IP69K | LED | 32 VDC | 10 VDC | Unshielded | 1 kHz | Stainless Steel | 70 °C | -40 C | 4 mm | 0.157 in | Cable Leads | Cylinder Threaded - M8 | |
 Omron Automation and Safety | Inductive | PNP-NO | IP67 IP69K | LED | 32 VDC | 10 VDC | Unshielded | 1 kHz | Stainless Steel | 70 °C | -40 C | 4 mm | 0.157 in | Connector | Cylinder Threaded - M8 | 3 |
 Omron Automation and Safety | Inductive | PNP-NO | IP67 IP69K | LED | 32 VDC | 10 VDC | Shielded | 1.5 kHz | Stainless Steel | 70 °C | -40 C | 2 mm | 0.079 in | Connector | Cylinder Threaded - M8 | 3 |
Omron Automation and Safety | Inductive | 3-Wire NPN-NO | IP67 IP69K | LED | 32 VDC | 10 VDC | Unshielded | 1 kHz | Stainless Steel | 70 °C | -40 C | 4 mm | 0.157 in | Cable Leads | Cylinder Threaded - M8 | |
 Omron Automation and Safety | Inductive | 3-Wire NPN-NO | IP67 IP69K | LED | 32 VDC | 10 VDC | Shielded | 1.5 kHz | Stainless Steel | 70 °C | -40 C | 2 mm | 0.079 in | Cable Leads | Cylinder Threaded - M8 | |
Omron Automation and Safety | Inductive | 3-Wire NPN-NC | IP67 IP69K | LED | 32 VDC | 10 VDC | Unshielded | 1 kHz | Stainless Steel | 70 °C | -40 C | 4 mm | 0.157 in | Connector | Cylinder Threaded - M8 | |
 Omron Automation and Safety | Inductive | PNP-NO | IP67 IP69K | LED | 32 VDC | 10 VDC | Shielded | 1.5 kHz | Stainless Steel | 70 °C | -40 C | 2 mm | 0.079 in | Cable Leads | Cylinder Threaded - M8 | 3 |
