342-90 Series
Manufacturer: Mill-Max Manufacturing Corp.
Beta
⌘K
HEADER SOLDERTAIL SIP 32POS
| Part | Connector Type | Pitch | Pitch | Color | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Termination | Number of Rows | Contact Finish | Contact Type | Contact Finish Thickness - Post (Mating) [custom] | Contact Finish Thickness - Post (Mating) [custom] | Length - Tail | Length - Tail [x] | Contact Finish - Post (Mating) | Number of Positions | Length - Stack Height [z] | Length - Stack Height [z] | Length - Post (Mating) [x] | Length - Post (Mating) [x] | Length - Overall Pin [x] | Length - Overall Pin [x] | Length - Stack Height | Length - Stack Height [x] | Length - Stack Height [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Mill-Max Manufacturing Corp. | DIP DIL - Header | 0.1 " | 2.54 mm | Black | 200 Áin | 5.08 Ám | Through Hole | Solder | 1 | Tin-Lead | Post Extended | |||||||||||||||
 Mill-Max Manufacturing Corp. | 0.1 " | 2.54 mm | Black | Through Hole | Solder | 1 | 5.08 Ám | 200 Áin | 3.18 mm | 0.125 in | Tin-Lead | 19 | 0.585 in | 14.859 mm | 3.18 mm | 0.125 in | 21.2 mm | 0.835 in | ||||||||
Mill-Max Manufacturing Corp. | 0.1 " | 2.54 mm | Black | Through Hole | Solder | 1 | 5.08 Ám | 200 Áin | 3.18 mm | 0.125 in | Tin-Lead | 12 | 0.21 in | 3.18 mm | 0.125 in | 11.684 mm | 0.46 in | 5.334 mm | ||||||||
Mill-Max Manufacturing Corp. | 0.1 " | 2.54 mm | Black | Through Hole | Solder | 1 | 5.08 Ám | 200 Áin | 3.18 mm | 0.125 in | Tin-Lead | 36 | 0.335 in | 8.5 mm | 3.18 mm | 0.125 in | 14.859 mm | 0.585 in | ||||||||
Mill-Max Manufacturing Corp. | 0.1 " | 2.54 mm | Black | Through Hole | Solder | 1 | 5.08 Ám | 200 Áin | 3.18 mm | 0.125 in | Tin-Lead | 7 | 3.18 mm | 0.125 in | 27.559 mm | 1.085 in | 0.835 in | 21.2 mm | ||||||||
Mill-Max Manufacturing Corp. | 0.1 " | 2.54 mm | Black | Through Hole | Solder | 1 | 5.08 Ám | 200 Áin | 3.18 mm | 0.125 in | Tin-Lead | 56 | 3.18 mm | 0.125 in | 27.559 mm | 1.085 in | 0.835 in | 21.2 mm | ||||||||
Mill-Max Manufacturing Corp. | 0.1 " | 2.54 mm | Black | Through Hole | Solder | 1 | 5.08 Ám | 200 Áin | 3.18 mm | 0.125 in | Tin-Lead | 27 | 0.21 in | 3.18 mm | 0.125 in | 11.684 mm | 0.46 in | 5.334 mm | ||||||||
Mill-Max Manufacturing Corp. | 0.1 " | 2.54 mm | Black | Through Hole | Solder | 1 | 5.08 Ám | 200 Áin | 3.18 mm | 0.125 in | Tin-Lead | 4 | 3.18 mm | 0.125 in | 27.559 mm | 1.085 in | 0.835 in | 21.2 mm | ||||||||
Mill-Max Manufacturing Corp. | 0.1 " | 2.54 mm | Black | Through Hole | Solder | 1 | 5.08 Ám | 200 Áin | 3.18 mm | 0.125 in | Tin-Lead | 6 | 3.18 mm | 0.125 in | 27.559 mm | 1.085 in | 0.835 in | 21.2 mm | ||||||||
Mill-Max Manufacturing Corp. | 0.1 " | 2.54 mm | Black | Through Hole | Solder | 1 | 5.08 Ám | 200 Áin | 3.18 mm | 0.125 in | Tin-Lead | 0.21 in | 3.18 mm | 0.125 in | 11.684 mm | 0.46 in | 5.334 mm |
