HDR-150 Series

Catalog

AC/DC DIN RAIL SUPPLY 15V 143W

Part	Current - Output (Max) [Max]	Voltage - Output 1	Features	DC Voltage - Input (Min) [Min]	Power (Watts)	Operating Temperature [Min]	Operating Temperature [Max]	DC Voltage - Input (Max) [Max]	Approval Agency	Applications	Voltage - Isolation	AC Voltage - Input [Max]	AC Voltage - Input [Min]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Input Type	Number of Outputs	Efficiency
MEAN WELL USA Inc. HDR-150-15	9.5 A	15 V	Adjustable Output Universal Input	120 V	143 W	-30 °C	70 °C	370 V	CB CE cULus cURus EAC TUV	ITE (Commercial) Laboratory	4000 V	264 VAC	85 VAC	3.54 "	4.13 in	2.15 in	105 mm	54.5 mm	90 mm	AC or DC	1
MEAN WELL USA Inc. HDR-150-12	11.3 A	12 V	Adjustable Output Universal Input	120 V	136 W	-30 °C	70 °C	370 V	CB CE cULus cURus EAC TUV	ITE (Commercial) Laboratory	4000 V	264 VAC	85 VAC	3.54 "	4.13 in	2.15 in	105 mm	54.5 mm	90 mm	AC or DC	1	89 %
MEAN WELL USA Inc. HDR-150-24	6.25 A	24 V	Adjustable Output Universal Input	120 V	156 W	-30 °C	70 °C	370 V	CB CE cULus cURus EAC TUV	ITE (Commercial) Laboratory	4000 V	264 VAC	85 VAC	3.54 "	4.13 in	2.15 in	105 mm	54.5 mm	90 mm	AC or DC	1	90.5 %
