E2A-M30 Series
Manufacturer: Omron Automation and Safety
Beta
⌘K
SENSOR PROX INDUCTIVE 20MM CYL
| Part | Output Type | Ingress Protection | Termination Style | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Supply [Max] | Voltage - Supply [Min] | Response Frequency | Sensing Distance | Sensing Distance | Package / Case | Indicator | Material - Body | Sensor Type | Shielding | Output Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Automation and Safety | 3-Wire NPN-NC/NO | IP67 IP69K | Connector | 70 °C | -40 C | 32 VDC | 10 VDC | 100 Hz | 20 mm | 0.787 in | Cylinder Threaded - M30 | LED | Nickel-Plated Brass | Inductive | Unshielded | |
 Omron Automation and Safety | PNP-NO | IP67 IP69K | Cable Leads | 70 °C | -40 C | 32 VDC | 10 VDC | 250 Hz | 15 mm | 0.591 in | Cylinder Threaded - M30 | LED | Nickel-Plated Brass | Inductive | Shielded | 3 |
Omron Automation and Safety | 3-Wire NPN-NC | IP67 IP69K | Cable Leads | 70 °C | -40 C | 32 VDC | 10 VDC | 250 Hz | 15 mm | 0.591 in | Cylinder Threaded - M30 | LED | Nickel-Plated Brass | Inductive | Shielded | |
Omron Automation and Safety | PNP-NO | IP67 IP69K | Cable Leads | 70 °C | -40 C | 32 VDC | 10 VDC | 250 Hz | 15 mm | 0.591 in | Cylinder Threaded - M30 | LED | Nickel-Plated Brass | Inductive | Shielded | 3 |
 Omron Automation and Safety | 2-Wire NPN-NO | IP67 IP69K | Cable Leads | 70 °C | -40 C | 32 VDC | 10 VDC | 250 Hz | 15 mm | 0.591 in | Cylinder Threaded - M30 | LED | Nickel-Plated Brass | Inductive | Shielded | |
Omron Automation and Safety | 3-Wire NPN-NC | IP67 IP69K | Cable Leads | 70 °C | -40 C | 32 VDC | 10 VDC | 250 Hz | 15 mm | 0.591 in | Cylinder Threaded - M30 | LED | Nickel-Plated Brass | Inductive | Shielded | |
 Omron Automation and Safety | PNP-NO | IP67 IP69K | Cable Leads | 70 °C | -40 C | 32 VDC | 10 VDC | 100 Hz | 20 mm | 0.787 in | Cylinder Threaded - M30 | LED | Nickel-Plated Brass | Inductive | Unshielded | 3 |
 Omron Automation and Safety | 3-Wire NPN-NC/NO | IP67 IP69K | Cable Leads | 70 °C | -40 C | 32 VDC | 10 VDC | 100 Hz | 20 mm | 0.787 in | Cylinder Threaded - M30 | LED | Nickel-Plated Brass | Inductive | Unshielded | |
Omron Automation and Safety | PNP-NO | IP67 IP69K | Cable Leads | 70 °C | -40 C | 32 VDC | 10 VDC | 100 Hz | 20 mm | 0.787 in | Cylinder Threaded - M30 | LED | Nickel-Plated Brass | Inductive | Unshielded | 3 |
Omron Automation and Safety | PNP-NC | IP67 IP69K | Connector | 70 °C | -40 C | 32 VDC | 10 VDC | 250 Hz | 15 mm | 0.591 in | Cylinder Threaded - M30 | LED | Nickel-Plated Brass | Inductive | Shielded | 3 |
