ESS75 Series
Manufacturer: ETA-USA
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
AC/DC CONVERTER 24V 77W
| Part | Efficiency | Applications | Power (Watts) | Standard Number | Voltage - Input (DC) Maximum | Voltage - Input (AC) Minimum | Voltage - Input (DC) Minimum | Voltage - Input (AC) Maximum | Current - Output 1 | Voltage - Output 1 | Number of Outputs | Features | Mounting Type | Type | Approval Agency | Size / Dimension Width | Size / Dimension Height | Size / Dimension Length | Operating Temperature (Min) | Operating Temperature (Max) | Voltage - Isolation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ETA-USA | 89.5 % | Industrial ITE (Commercial) | 77 W | 60950-1 UL 508 | 350 VDC | 85 VAC | 110 V | 264 V | 3.2 A | 24 V | 1 | Adjustable Output Remote Sense Universal Input | Chassis Mount | Enclosed | CE CSA cURus SEMKO | 1.3 in | 3.11 in | 5.16 in | -10 °C | 71 °C | 3 kV |
