har-flex-r-power Series

Manufacturer: HARTING

Catalog

PCB RECEPTACLE, BOARD-TO-BOARD, 2.54 MM, 1 ROWS, 2 CONTACTS, SURFACE MOUNT STRAIGHT

Part	Contact Shape	Contact Material	Applications	Insulation Material	Number of Rows	Termination	Contact Finish - Post	Features	Number of Positions Loaded	Insulation Height	Insulation Height	Current Rating (Amps)	Contact Type	Fastening Type	Insulation Color	Number of Positions	Mounting Type	Material Flammability Rating	Connector Type	Pitch - Mating	Pitch - Mating	Contact Finish - Mating	Operating Temperature [Min]	Operating Temperature [Max]	Style	Shrouding	Insulation Height [z]	Insulation Height [z]	Contact Length - Post	Contact Length - Post	Contact Length - Mating	Contact Length - Mating
HARTING 15620022601000	Square	Copper Alloy	General Purpose	Liquid Crystal Polymer (LCP)	1	Solder	Tin	Board Guide Pick and Place Solder Retention	All	0.356 "	9.05 mm	25 A	Female Socket	Push-Pull	Black	2	Surface Mount	UL94 V-0	Receptacle	0.1 "	2.54 mm	Gold	-55 C	125 °C	Board to Board Cable
HARTING 15650122601000	Square	Copper Alloy	General Purpose	Liquid Crystal Polymer (LCP)	1	Solder	Tin	Board Guide Solder Retention	All	0.145 in	3.68 mm	18 A	Female Socket	Push-Pull	Black	12	Right Angle Surface Mount	UL94 V-0	Receptacle	0.1 "	2.54 mm	Gold	-55 C	125 °C	Board to Board Cable
HARTING 15520052701000	Rectangular	Copper Alloy		Liquid Crystal Polymer (LCP)	1	Solder	Tin	Board Guide Board Lock Pick and Place	All			20 A	Male Pin	Push-Pull	Black	5	Through Hole	UL94 V-0	Header	0.1 "	2.54 mm	Gold	-55 C	125 °C	Board to Cable/Wire	Shrouded - 4 Wall	0.319 in	8.1 mm	2.5 mm	0.098 in
HARTING 15550122601000	Rectangular	Copper Alloy		Liquid Crystal Polymer (LCP)	1	Solder	Tin	Board Guide Solder Retention	All	0.167 "	4.25 mm	18 A	Male Pin	Push-Pull	Black	12	Right Angle Surface Mount	UL94 V-0	Header	0.1 "	2.54 mm	Gold	-55 C	125 °C	Board to Board Cable	Shrouded - 4 Wall	0.167 in	4.24 mm
HARTING 15650122701000	Square	Copper Alloy	General Purpose	Liquid Crystal Polymer (LCP)	1	Solder	Tin	Board Guide Solder Retention	All	0.12 in	3.05 mm	19 A	Female Socket	Push-Pull	Black	12	Right Angle Through Hole	UL94 V-0	Receptacle	0.1 "	2.54 mm	Gold	-55 C	125 °C	Board to Board Cable				2.2 mm	0.087 in
HARTING 15650022601000	Square	Copper Alloy	General Purpose	Liquid Crystal Polymer (LCP)	1	Solder	Tin	Board Guide Solder Retention	All	0.145 in	3.68 mm	26 A	Female Socket	Push-Pull	Black	2	Right Angle Surface Mount	UL94 V-0	Receptacle	0.1 "	2.54 mm	Gold	-55 C	125 °C	Board to Board Cable
HARTING 15520122601000	Rectangular	Copper Alloy		Liquid Crystal Polymer (LCP)	1	Solder	Tin	Board Guide Pick and Place Solder Retention	All			18 A	Male Pin	Push-Pull	Black	12	Surface Mount	UL94 V-0	Header	0.1 "	2.54 mm	Gold	-55 C	125 °C	Board to Board Cable	Shrouded - 4 Wall	0.319 in	8.1 mm			4.6 mm	0.181 in
HARTING 15620122701000	Square	Copper Alloy	General Purpose	Liquid Crystal Polymer (LCP)	1	Solder	Tin	Board Guide Pick and Place Solder Retention	All	0.356 "	9.05 mm	19 A	Female Socket	Push-Pull	Black	12	Through Hole	UL94 V-0	Receptacle	0.1 "	2.54 mm	Gold	-55 C	125 °C	Board to Board Cable				2.5 mm	0.098 in
