19K101 Series
Manufacturer: Rosenberger
Beta
⌘K
CONN SMP JACK STR 50OHM SOLDER
| Part | Body Material | Center Contact Plating | Voltage Rating | Body Finish | Operating Temperature [Max] | Operating Temperature [Min] | Dielectric Material | Contact Termination | Frequency - Max [Max] | Number of Ports | Shield Termination | Housing Color | Fastening Type | Mounting Type | Center Contact Material | Impedance | Connector Type | Cable Group | Style | Convert From (Adapter End) | Convert To (Adapter End) | Center Gender | Conversion Type | Fastening Type | Adapter Type | Adapter Series |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rosenberger | Beryllium Copper | Gold | 335 V | Gold | 155 C | -65 ░C | Polytetrafluoroethylene (PTFE) | Solder | 26.5 GHz | 1 | Solder | Gold | Snap-On | Free Hanging (In-Line) | Beryllium Copper | 50 Ohms | Female Socket Jack | |||||||||
 Rosenberger | Beryllium Copper | Gold | 335 V | Gold | 155 C | -65 ░C | Polytetrafluoroethylene (PTFE) | Crimp | 26.5 GHz | 1 | Crimp | Gold | Snap-On | Free Hanging (In-Line) | Beryllium Copper | 50 Ohms | Female Socket Jack | RG-316 | ||||||||
 Rosenberger | Beryllium Copper | Gold | 335 V | Gold | 155 C | -65 ░C | Polytetrafluoroethylene (PTFE) | Solder | 26.5 GHz | 1 | Solder | Gold | Snap-On | Free Hanging (In-Line) | Beryllium Copper | 50 Ohms | Female Socket Jack | RG-405 (.085" Semi Rigid) | ||||||||
 Rosenberger | Beryllium Copper | Gold | 335 V | Gold | 155 C | -65 ░C | Polytetrafluoroethylene (PTFE) | Crimp | 26.5 GHz | 1 | Crimp | Gold | Snap-On | Free Hanging (In-Line) | Beryllium Copper | 50 Ohms | Female Socket Jack | 188A 316 RG-174A | ||||||||
 Rosenberger | Beryllium Copper | Gold | Gold | 155 C | -65 ░C | Polytetrafluoroethylene (PTFE) | 26.5 GHz | Snap-On | Free Hanging (In-Line) | Beryllium Copper | 50 Ohms | Straight | Female Socket SMP Jack | SMP Jack Female Socket | Female to Female | Same Series | Snap-On | Jack to Jack | SMP to SMP |
