Nch 60V 15.5A, HSMT8, Power MOSFET
Description
AI
RQ3L060BG is a power MOSFET with low-on resistance and High power package, suitable for switching, motor drives and DC/DC converter.
Beta
⌘K
Nch 60V 15.5A, HSMT8, Power MOSFET
Nch 60V 15.5A, HSMT8, Power MOSFET
| Part | Vgs (Max) | Current - Continuous Drain (Id) @ 25°C | Technology | Drain to Source Voltage (Vdss) | Rds On (Max) @ Id, Vgs | Power Dissipation (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Type | Package / Case | Operating Temperature | Mounting Type | Gate Charge (Qg) (Max) @ Vgs | Drive Voltage (Max Rds On, Min Rds On) | Vgs(th) (Max) @ Id | Supplier Device Package [x] | Supplier Device Package [custom] | Supplier Device Package [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | 20 V | 6 A 15.5 A | MOSFET (Metal Oxide) | 60 V | 38 mOhm | 2 W 14 W | 310 pF | N-Channel | 8-PowerVDFN | 150 °C | Surface Mount | 5.5 nC | 4.5 V 10 V | 2.5 V | 3.2 | 8-HSMT | 3 |
