895-025 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 25POS 0.100
| Part | Termination Rows | Material - Insulation | Operating Temperature [Max] | Operating Temperature [Min] | Contact Type | Gender | Card Type | Number of Rows | Color | Contact Material | Number of Positions/Bay/Row | Contact Finish | Pitch | Pitch | Flange Feature | Termination | Read Out | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Cantilever | Female | Non Specified - Single Edge | 1 | Black | Copper Alloy | 25 | Gold | 0.1 " | 2.54 mm | 4-40 Threaded Insert Top Mount Opening | Solder | Single | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Right Angle Through Hole | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Cantilever | Female | Non Specified - Single Edge | 1 | Black | Copper Alloy | 25 | Gold | 0.1 " | 2.54 mm | Wire Wrap | Single | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Through Hole | 0.156 " | 3.96 mm | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Cantilever | Female | Non Specified - Single Edge | 1 | Black | Copper Alloy | 25 | Gold | 0.1 " | 2.54 mm | Solder Eyelet(s) | Single | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Through Hole | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Cantilever | Female | Non Specified - Single Edge | 1 | Black | Copper Alloy | 25 | Gold | 0.1 " | 2.54 mm | M3 Threaded Insert Top Mount Opening | Solder | Single | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Through Hole | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Cantilever | Female | Non Specified - Single Edge | 1 | Black | Copper Alloy | 25 | Gold | 0.1 " | 2.54 mm | Wire Wrap | Single | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Through Hole | 0.156 " | 3.96 mm | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Cantilever | Female | Non Specified - Single Edge | 1 | Black | Copper Alloy | 25 | Gold | 0.1 " | 2.54 mm | Flush Mount Top Opening Unthreaded | Wire Wrap | Single | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Through Hole | 0.128 " | 3.25 mm |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Cantilever | Female | Non Specified - Single Edge | 1 | Black | Copper Alloy | 25 | Gold | 0.1 " | 2.54 mm | 4-40 Threaded Insert Top Mount Opening | Solder | Single | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Through Hole | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Cantilever | Female | Non Specified - Single Edge | 1 | Black | Copper Alloy | 25 | Gold | 0.1 " | 2.54 mm | M3 Threaded Insert Top Mount Opening | Solder | Single | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Through Hole | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Cantilever | Female | Non Specified - Single Edge | 1 | Black | Copper Alloy | 25 | Gold | 0.1 " | 2.54 mm | M3 Threaded Insert Top Mount Opening | Solder | Single | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Right Angle Through Hole | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 125 °C | -40 C | Cantilever | Female | Non Specified - Single Edge | 1 | Black | Copper Alloy | 25 | Gold | 0.1 " | 2.54 mm | Flush Mount Side Opening Unthreaded | Solder | Single | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Through Hole | 0.128 " | 3.25 mm |
