MMT361A Series
Manufacturer: METZ CONNECT USA Inc.
Beta
⌘K
CONN JACK FMALE 8POS SOLDER
| Part | Orientation [x] | Ingress Protection | Number of Positions | Connector Type | Mounting Type | Termination | Shell Size - Insert | Applications | Color | Fastening Type | Operating Temperature [Max] | Operating Temperature [Min] | Features | Mounting Feature | Primary Material | Shell Material | Insert Material [custom] | Insert Material [custom] | Voltage Rating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Material Flammability Rating | Contact Finish - Mating | Shielding | Current Rating (Amps) | Orientation | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 METZ CONNECT USA Inc. | X | IP67 - Dust Tight Waterproof | 8 | Jack Female Sockets | Panel Mount Through Hole | Solder | M12-8 | Railway | Silver | Threaded | 85 °C | -40 C | Potted | Bulkhead - Rear Side Nut | |||||||||||||
 METZ CONNECT USA Inc. | IP67 - Dust Tight Waterproof | 4 | Jack Female Sockets | Panel Mount Through Hole | Solder | M12-4 | Industrial | Silver | Threaded | 85 °C | -40 C | Board Guide | Bulkhead - Rear Side Nut | Metal | Copper Zinc | Nylon | Polyamide (PA) | 250 V | 7.87 Áin | 0.2 Ám | UL94 V-0 | Gold | Shielded | 4 A | D | Copper Zinc | |
 METZ CONNECT USA Inc. | X | IP67 - Dust Tight Waterproof | 8 | Jack Female Sockets | Panel Mount Through Hole | Solder | M12-8 | Railway | Silver | Threaded | 85 °C | -40 C | Board Guide | Bulkhead - Rear Side Nut | Metal | Copper Zinc | 50 VAC 60 VDC | 8 µin | 0.203 µm | Gold | Shielded | Copper Zinc | |||||
 METZ CONNECT USA Inc. | X | IP67 - Dust Tight Waterproof | 8 | Jack Female Sockets | Panel Mount Through Hole | Solder | M12-8 | Railway | Silver | Threaded | 85 °C | -40 C | Bulkhead - Rear Side Nut | Metal | Copper Zinc | 48 VDC | Gold | Shielded | 0.5 A | Copper Zinc | |||||||
 METZ CONNECT USA Inc. | IP67 - Dust Tight Waterproof | 4 | Jack Female Sockets | Panel Mount Through Hole | Solder | M12-4 | Industrial | Silver | Threaded | 85 °C | -40 C | Board Guide Potted | Bulkhead - Rear Side Nut | Metal | Copper Zinc | Nylon | Polyamide (PA) | 250 V | 7.87 Áin | 0.2 Ám | UL94 V-0 | Gold | Shielded | 4 A | D | Copper Zinc | |
 METZ CONNECT USA Inc. | IP67 - Dust Tight Waterproof | 4 | Jack Female Sockets | Panel Mount Through Hole | Solder | M12-4 | Industrial | Silver | Threaded | 85 °C | -40 C | Board Guide | Bulkhead - Rear Side Nut | Metal | Copper Zinc | Nylon | Polyamide (PA) | 250 V | 7.87 Áin | 0.2 Ám | UL94 V-0 | Gold | Shielded | 4 A | D | Copper Zinc |
