Nch 600V 33A, TO-3PF, Power MOSFET
Description
AI
R6086YNZ is a power MOSFET with low on - resistance, suitable for switching.
Beta
⌘K
Nch 600V 33A, TO-3PF, Power MOSFET
Nch 600V 33A, TO-3PF, Power MOSFET
| Part | Drain to Source Voltage (Vdss) | Technology | Rds On (Max) @ Id, Vgs | Package / Case | Supplier Device Package | Drive Voltage (Max Rds On, Min Rds On) | Current - Continuous Drain (Id) @ 25°C | Input Capacitance (Ciss) (Max) @ Vds [Max] | Vgs(th) (Max) @ Id | Power Dissipation (Max) | FET Type | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Mounting Type | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | 600 V | MOSFET (Metal Oxide) | 44 mOhm | TO-3P-3 Full Pack | TO-3PF | 10 V 12 V | 33 A | 5100 pF | 6 V | 114 W | N-Channel | 110 nC | 30 V | Through Hole | 150 °C |
